White circular disc-shaped access point with flat top and mounting bracket

Ubiquiti Networks

Ubiquiti Networks Wave Nano 60 GHz PtMP access point

SKU CH-1VKY-A4M5Y

A 60 GHz PtMP station delivering up to 2 Gbps total throughput with a 5 GHz backup radio and GPS for reliable outdoor links

  • Frequency BandRF Operating frequency* 57–71 GHz *Depends on regulatory reg
  • LEDsPower Flashing white: bootup in progress White: not connecte
  • ButtonsFactory reset
  • LAN Ports(1) GbE RJ45 port
  • Power SupplyMax. power consumption 20W Power method Passive PoE 4-pairs
  • Temperature-40 to 60° C (-40 to 140° F)
  • Delivers up to 2 Gbps total throughput over 60 GHz link
  • 5 GHz backup radio provides up to 800 Mbps failover connectivity
  • Operates reliably from -40 °C to 60 °C ambient temperature
  • Powered via included 48 V 0.65 A passive PoE adapter
  • Managed through UISP mobile app using integrated Bluetooth radio

Product identity

The Ubiquiti Networks Wave Nano is a 60 GHz PtMP wireless access point designed for point-to-multipoint network deployments. It delivers up to 2 Gbps total throughput with 1 Gbps duplex capacity. A 5 GHz backup radio provides up to 800 Mbps for link redundancy. The unit includes a 48V 0.65A gigabit PoE adapter.

Suitability

This device suits installers building 60 GHz PtMP links up to 5 km who need integrated GPS and Bluetooth for UISP mobile app management. It is not for buyers who require a PtP-only radio without PtMP capability, who need more than one gigabit Ethernet port, or who cannot supply passive PoE in the 44 to 54V DC range.

Deciding specification

The operating band of 57 to 71 GHz determines whether this radio matches your spectrum licence and link planning. Regional regulations control the exact channels available from the listed set starting at 58320 MHz.

Highlights

  • Delivers up to 2 Gbps total throughput over 60 GHz link
  • 5 GHz backup radio provides up to 800 Mbps failover connectivity
  • Operates reliably from -40 °C to 60 °C ambient temperature
  • Powered via included 48 V 0.65 A passive PoE adapter
  • Managed through UISP mobile app using integrated Bluetooth radio

Specifications

BrandUbiquiti Network
SeriesWave 60 GHz
ModelWave-Nano
Frequency BandRF
Operating frequency* 57–71 GHz
*Depends on regulatory region.
Channel bandwidth 2160, 1080, 540* MHz
*FW version 3.3.0 and later.
Operating channels* 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz
*Depends on regulatory region.
Modulation 16QAM, QPSK
Antenna gain 41 dBi
Polarization Vertically linear
Beamwidth Azimuth: 3 dB 1.4°
Elevation: 3 dB 1.4°
Back-Up RF
WiFi standard 802.11ax (WiFi 6)
Operating frequency*
US/CA
Worldwide
U-NII-1 5150 - 5250 MHz
U-NII-2A 5250 - 5350 MHz
U-NII-2C 5470 - 5725 MHz
U-NII-3 5725 - 5850 MHz
5150 - 5875 MHz
*
LEDsPower Flashing white: bootup in progress
White: not connected to UISP application
Blue: connected to UISP application
Flashing blue: locate in progress
Blue/white: firmware upgrade in progress
Ethernet Flashing blue: Ethernet traffic detected
GPS Blue: receiving at least (4) GPS satellite signal
Links White: 5 GHz link
Blue: 60 GHz link
ButtonsFactory reset
LAN Ports(1) GbE RJ45 port
Power SupplyMax. power consumption 20W
Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only
Power supply 48V DC, 0.65A gigabit PoE adapter (Included)
Can be powered by a UISP Router or UISP Switch
Temperature-40 to 60° C (-40 to 140° F)
Humidity5 to 95% noncondensing
DimensionsØ256.5 x 113.5 mm (Ø10.1 x 4.5")
WeightWithout mount: 932 g (2.1 lb)
With mount: 1.2 kg (2.6 lb)
FeaturesHardware
Processor Dual-core ARM® Cortex®-A53 at 1 GHz
Memory DDR3L 512 MB
Software
Operating mode PtMP station, PtP*
*FW version 3.2.0 and later.
Ubiquiti specific features Wave AI, discovery protocol
Services UISP, ping watchdog, NTP client, SNMP
Tools Antenna alignment, discovery utility, ping, trace route, speed test, cable test*, site survey*
*FW version 3.3.0 and later.
Network Bridge/Router* mode
*Router is available in PtMP station mode only.
Application requirements UISP: Version 1.4.5 and later
System
Total throughput 2 Gbps (1 Gbps duplex)
Max. range 5+ km
Encryption WPA2-
Shipping weight2.47 kg
Package size305 × 302 × 193 mm

Questions about this item

What comes in the box and what must I buy separately?

The Wave Nano includes a 48 V, 0.65 A gigabit PoE adapter. It connects via a single GbE RJ45 port and has a factory-reset button; no separate PoE injector is required.

Which firmware version should I run for PtP mode and 540 MHz channels?

PtP operation needs firmware 3.2.0 or later, while 540 MHz channel bandwidth is available from 3.3.0 onward.

What does the 2 Gbps total throughput mean in practice?

It delivers 1 Gbps duplex over the 60 GHz link, with an 800 Mbps 5 GHz backup radio that keeps the connection alive in rain or fog.
