White square ceiling-mounted access point with two Ethernet ports and reset button

Ubiquiti Networks

Ubiquiti Networks UAP-AC-HD 802.11ac Wave 2 MU-MIMO access point

SKU CH-G36A-BAZSY

Enterprise dual-band Wi-Fi access point delivering up to 1.7 Gbps with 4x4 MU-MIMO and PoE+ power

  • Standards802.11a/b/g/n/ac/ac-wave2
  • Wireless Data RatesUp to 1.7Gbps
  • SecurityWEP, WPA-PSK, WPA-Enterprise (WPA / WPA2, TKIP / AES) 802.11
  • Frequency Band2.4 GHz / 5 GHz
  • Antenna2.4 GHz: 2 x Dual-Port, Dual-Polarity Antennas, 3 dBi each 5
  • Interface2 x 10/100/1000 Ethernet Ports
  • Simultaneous dual-band 4x4 MU-MIMO serves many devices at once
  • 11ac Wave 2 four-stream design delivers up to 1.7Gbps throughput
  • Dual Gigabit Ethernet ports with 802.3at PoE+ simplify installation and power
  • Wide operating range of -10 to 70°C suits indoor and covered outdoor use
  • Compact 1.89" x 8.66" x 8.66" form factor weighs only 1.54 lbs for easy mounting

Dual-band 802.11ac Wave 2 access point

The Ubiquiti Networks UAP-AC-HD is an enterprise-grade wireless access point that delivers simultaneous dual-band operation with 4x4 MU-MIMO technology. It supports data rates up to 1.7Gbps aggregate throughput across 2.4 GHz and 5 GHz bands. The unit includes wall and ceiling mounting kits for indoor or covered outdoor deployment and connects via two Gigabit Ethernet ports powered by 802.3at PoE+.

High-density environments needing Wave 2 performance

This access point suits offices, schools and venues that require four-stream 802.11ac Wave 2 capacity for many concurrent clients. It operates from -10 to 70 Celsius with 5 to 95 percent non-condensing humidity. Buyers who need 802.11ax or later Wi-Fi standards, single-port PoE devices, or standalone power injectors should consider other solutions.

802.3at PoE+ power requirement

The UAP-AC-HD draws a maximum of 17W and requires an 802.3at PoE+ source supplying 44 to 57V DC, typically a UniFi Switch. Without a compliant PoE+ switch or injector the access point will not power on. Verify your network infrastructure can deliver 802.3at before purchase.

Highlights

  • Simultaneous dual-band 4x4 MU-MIMO serves many devices at once
  • 11ac Wave 2 four-stream design delivers up to 1.7Gbps throughput
  • Dual Gigabit Ethernet ports with 802.3at PoE+ simplify installation and power
  • Wide operating range of -10 to 70°C suits indoor and covered outdoor use
  • Compact 1.89" x 8.66" x 8.66" form factor weighs only 1.54 lbs for easy mounting

Specifications

BrandUbiquiti Networks
ModelUAP-AC-HD
Standards802.11a/b/g/n/ac/ac-wave2
Wireless Data RatesUp to 1.7Gbps
SecurityWEP, WPA-PSK, WPA-Enterprise (WPA / WPA2, TKIP / AES) 802.11 w/ PMF
Frequency Band2.4 GHz / 5 GHz
Antenna2.4 GHz: 2 x Dual-Port, Dual-Polarity Antennas, 3 dBi each
5 GHz: 2 x Dual-Port, Dual-Polarity Antennas, 4 dBi each
Interface2 x 10/100/1000 Ethernet Ports
ButtonsReset
Power SupplyPower Method: 802.3at PoE+
Supported Voltage Range: 44 to 57V DC
Power Supply: UniFi Switch (PoE)
Power Save: Supported
Maximum Power Consumption: 17W
TemperatureOperating Temperature: -10 ~ 70 degree Celsius (14 ~ 158 degree Fahrenheit)
HumidityOperating Humidity: 5% ~ 95% non-condensing
Dimensions1.89" x 8.66" x 8.66"
Weight1.54 lbs.
1.83 lbs. (With Mounting Kits)
FeaturesSimultaneous Dual-Band 4x4 Multi-User MIMO
Four-Stream 802.11ac Wave 2 Technology
802.3at PoE+ Compatibility

Questions about this item

Will the UAP-AC-HD work with my existing 802.11n clients on the 2.4 GHz band?

Yes, the access point supports 802.11a/b/g/n/ac/ac-wave2 standards, so legacy 802.11n devices connect at their native rates on 2.4 GHz.

How can I verify the AP is operating at the advertised 1733 Mbps on 5 GHz after installation?

In the UniFi controller, check the client dashboard for 4x4 MU-MIMO links showing PHY rates up to 1733 Mbps on the 5 GHz radio.

Does the box include a PoE+ injector or must I buy a compatible switch separately?

The package supplies wall and ceiling mount kits only; power is delivered via 802.3at PoE+ from a UniFi switch or other compliant source you provide.
