Ubiquiti Networks
Ubiquiti Networks U5G-Max 5G modem 3.4 Gbps 2.5 GbE PoE
A high-performance 5G modem reaching 3.4 Gbps with a 2.5 GbE port, dual SIM or eSIM, PoE power and a 1.3" touchscreen
- Dimension180 x 109 x 33.8 mm (7.1 x 4.3 x 1.3")
- WeightDevice: 410 g (14.5 oz)
- FeaturesNetworking Interface: (1) 2.5 GbE RJ45 port 5G NR and LTE ra
- Up to 3.4 Gbps 5G downlink speed for fast UniFi connectivity
- Dual Nano SIM or eSIM slots enable carrier failover and flexibility
- Powered and adopted via a single 2.5 GbE PoE port for simple deployment
- 3 inch touchscreen provides local status and management at a glance
- Certified for AT&T and T-Mobile networks with Verizon support coming soon
5G Modem for UniFi Networks
The Ubiquiti U5G-Max is a 5G NR and LTE modem built for UniFi deployments. It delivers up to 3.4 Gbps downlink in NSA mode and connects through a single 2.5 GbE RJ45 port. The device requires a UniFi Network console running version 10.0.162 or later and an alternative WAN connection for initial adoption.
PoE Powered with Dual SIM Flexibility
Installation is simplified because the modem draws power entirely from a UniFi PoE port and includes desktop stand, wall mount and window mount hardware. A Nano SIM slot and a second slot accepting either Nano SIM or eSIM provide carrier redundancy. The 1.3 inch touchscreen and factory reset button allow local status checks without a console.
Sustained Throughput and Carrier Certification
Under continuous load the modem maintains 5G SA speeds of 1.8 Gbps downlink and 650 Mbps uplink, while 4G LTE reaches 1.6 Gbps downlink. Maximum power consumption is 14.5 W. The unit is certified for AT&T and T-Mobile data-only plans; Verizon support is not yet available and T-Mobile Home Internet SIMs are not supported.
Highlights
- Up to 3.4 Gbps 5G downlink speed for fast UniFi connectivity
- Dual Nano SIM or eSIM slots enable carrier failover and flexibility
- Powered and adopted via a single 2.5 GbE PoE port for simple deployment
- 3 inch touchscreen provides local status and management at a glance
- Certified for AT&T and T-Mobile networks with Verizon support coming soon
Specifications
| Brand | Ubiquiti |
|---|---|
| Model | UniFi 5G Max |
| Part Number | U5G-Max |
| Dimension | 180 x 109 x 33.8 mm (7.1 x 4.3 x 1.3") |
| Weight | Device: 410 g (14.5 oz) |
| Features | Networking Interface: (1) 2.5 GbE RJ45 port 5G NR and LTE radio SIM: (1) Nano SIM (1) Nano-SIM or eSIM PoE Interface: (1) PoE input Mounting: Desktop stand, wall, window mount (Included) Tamper Resistance: IK04 Antennas: (4) Embedded cellular antennas Max. Power Consumption: 14.5W Power Method: PoE Display: 1.3" touchscreen Buttons: (1) Factory reset |
| Shipping weight | 0.91 kg |
| Package size | 203 × 127 × 76 mm |
Questions about this item
How do I confirm the U5G-Max is working correctly after connecting it to a UniFi PoE port?
The 1.3" touchscreen shows live signal strength and connection status; in the UniFi Network app (version 10.0.162 or later) the device appears as adopted with 5G NR or LTE active and reports downlink speeds up to 3.4 Gbps on 5G NSA.
What comes in the box with the U5G-Max and what must I supply separately?
The package includes the modem, a desktop stand, wall-mount and window-mount hardware; you must provide a PoE injector or PoE switch for power and an active nano SIM or eSIM with a data-only plan.
Which SIM option should I choose for the U5G-Max — single nano SIM or the dual nano SIM/eSIM slot?
The modem has one dedicated nano SIM slot and a second slot that accepts either a nano SIM or an eSIM; use the dual slot if you want carrier failover or a backup profile, otherwise the single nano SIM slot is sufficient.
