Ubiquiti Networks
Ubiquiti Networks LOCOM2-US 2.4 GHz 802.11n access point
2.4 GHz outdoor wireless access point with 8 dBi integrated antenna and 3.1 mile maximum range for point-to-multipoint links
- StandardsIEEE 802.11n
- Frequency Band2.412 GHz - 2.462 GHz
- Temperature-30 to 75° C Operating Temperature
- Humidity5 to 95% Condensing Operating Humidity 5
- Dimensions6.34" x 3.15" x 1.22" (H x W x D)
- Weight0.4lb
- 4 GHz 802.11n wireless link up to 150 Mbit/s
- 8 dBi integrated antenna reaches 3.1 mile outdoor range
- Passive PoE powers the unit over a single Ethernet cable
- Compact UV-stabilised housing operates from -30 to 75 °C
- Pole-mountable CPE installs with only a single wrench
Compact 2.4 GHz outdoor CPE
The Ubiquiti Networks LOCOM2-US is a NanoStation locoM2 wireless access point built for point-to-multipoint and point-to-point links. It operates on the 2.412 GHz to 2.462 GHz band using IEEE 802.11n at up to 150 Mbit/s. The integrated 8 dBi dual linear antenna delivers a maximum outdoor range of 3.1 miles.
Passive PoE and airMAX protocol
The unit is powered through passive Power over Ethernet on pairs 4, 5+ and 7, 8 return, so no separate mains adapter is needed at the mounting point. Ubiquiti’s airMAX TDMA protocol schedules time slots for each client, removing hidden node collisions and improving latency, throughput and scalability compared with standard Wi-Fi.
Suits WISPs and surveillance links.
Installers deploying cost-effective customer premises equipment or bridging video surveillance feeds will benefit from the plug-and-play pole mount and -30 to 75 °C operating range. Buyers needing 5 GHz spectrum, higher throughput than 150 Mbit/s or indoor mesh roaming should consider other product lines.
Highlights
- 4 GHz 802.11n wireless link up to 150 Mbit/s
- 8 dBi integrated antenna reaches 3.1 mile outdoor range
- Passive PoE powers the unit over a single Ethernet cable
- Compact UV-stabilised housing operates from -30 to 75 °C
- Pole-mountable CPE installs with only a single wrench
Specifications
| Brand | Ubiquiti Networks |
|---|---|
| Series | NanoStation locoM |
| Model | LOCOM2-US |
| Part Number | LOCOM2US |
| Standards | IEEE 802.11n |
| Frequency Band | 2.412 GHz - 2.462 GHz |
| Temperature | -30 to 75° C Operating Temperature |
| Humidity | 5 to 95% Condensing Operating Humidity 5 |
| Dimensions | 6.34" x 3.15" x 1.22" (H x W x D) |
| Weight | 0.4lb |
| Features | Cost-Effective, High-Performance Compact and Versatile Design Powerful Integrated Antenna Gain: 8 dBi Dual Linear Outdoor UV Stabilized Plastic Passive Power over Ethernet (pairs 4, 5+; 7, 8 return) |
| Shipping weight | 0.50 kg |
| Package size | 221 × 122 × 84 mm |
Questions about this item
How often should the UV-stabilized plastic enclosure be inspected or replaced after years of outdoor exposure?
The enclosure is UV-stabilized for outdoor durability; no scheduled replacement interval is defined, but visual inspection during routine site visits is recommended.
What is the maximum sustained throughput the 802.11n radio can deliver in a point-to-point link?
The radio is rated at 150 Mbit/s PHY rate; real-world sustained throughput will be lower due to overhead, interference and link distance.
How much heat does the unit generate when powered via passive PoE and running at full load all day?
It operates from -30 to 75 °C ambient with no active cooling; power draw is low, so heat output is minimal and passively dissipated.
