White rectangular outdoor access point with detachable horn antenna and metal base

Ubiquiti Networks

Ubiquiti Networks IS-5AC-US access point

SKU CH-GM3K-KTZXW MPN IS-5AC-US

5 GHz wireless access point with interchangeable isolation horn antenna, all-metal shielded radio base, gigabit PoE power and up to 450 Mbps throughput

  • Interface1 x 10/100/1000 Ethernet Port
  • LEDs1 x Power
  • Power SupplyMax. Power Consumption: 8.5W Power Supply: 24V, 0.5A Gigabit
  • TemperatureOperating Temperature: -40 ~ 70 degree Celsius (-40 ~ 158 de
  • HumidityOperating Humidity: 5% ~ 95% non-condensing
  • DimensionsWith Horn: 5.91" x 6.85" x 6.85" Without Horn: 2.56" x 5.16"
  • Interchangeable horn antennas shape the beam for targeted coverage
  • All-metal shielded base reduces interference in busy RF environments
  • airMAX ac processor delivers up to 450 Mbps real TCP/IP throughput
  • Gigabit Ethernet with 24 V passive PoE simplifies single-cable installation
  • Operates from -40 to 70 °C for reliable outdoor deployment

Versatile 5 GHz CPE

The Ubiquiti Networks IS-5AC-US is a new airMAX ac customer premises device built for fixed wireless links. It serves installers and network operators who need a cost-effective, high-performance radio for point-to-point or point-to-multipoint deployments. The integrated airMAX ac processor delivers up to 450+ Mbps real TCP/IP throughput. Its modular design simplifies network management across varied sites.

Shielded all-metal construction

An all-metal, shielded radio base protects the electronics from harsh outdoor conditions. The interchangeable isolation antenna horn attaches via a single-button release, letting technicians swap beam patterns without tools or extra connectors. A single 10/100/1000 Ethernet port handles data and passive PoE on pairs 4, 5+ and 7, 8 return. The package includes a 24V, 0.5A gigabit PoE adapter for straightforward power delivery.

Wide temperature tolerance

Operating temperature spans -40 to 70 degrees Celsius (-40 to 158 degrees Fahrenheit) with humidity tolerance from 5% to 95% non-condensing. Maximum power draw is 8.5W, keeping energy costs low for always-on links. The horn-equipped unit measures 5.91 by 6.85 by 6.85 inches and weighs 1.60 lbs; without the horn it reduces to 2.56 by 5.16 by 5.16 inches and 0.90 lb. A single power LED provides basic status indication.

Highlights

  • Interchangeable horn antennas shape the beam for targeted coverage
  • All-metal shielded base reduces interference in busy RF environments
  • airMAX ac processor delivers up to 450 Mbps real TCP/IP throughput
  • Gigabit Ethernet with 24 V passive PoE simplifies single-cable installation
  • Operates from -40 to 70 °C for reliable outdoor deployment

Specifications

BrandUbiquiti Networks
ModelIS-5AC-US
Interface1 x 10/100/1000 Ethernet Port
LEDs1 x Power
Power SupplyMax. Power Consumption: 8.5W
Power Supply: 24V, 0.5A Gigabit PoE Adapter
Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
TemperatureOperating Temperature: -40 ~ 70 degree Celsius (-40 ~ 158 degree Fahrenheit)
HumidityOperating Humidity: 5% ~ 95% non-condensing
DimensionsWith Horn: 5.91" x 6.85" x 6.85"
Without Horn: 2.56" x 5.16" x 5.16"
WeightWith Horn: 1.60 lbs.
Without Horn: 0.90 lb.
FeaturesInterchangeable Isolation Antenna Horn
All-Metal, Shielded Radio Base
airMAX ac Processor for Superior Performance
Shipping weight1.43 kg
Package size216 × 201 × 178 mm

Questions about this item

What real-world throughput does the 10/100/1000 Ethernet port cap at on the IS-5AC-US?

The Gigabit Ethernet port supports up to 450+ Mbps real TCP/IP throughput when used with airMAX ac technology.

What are the exact dimensions and weight for pole-mounting the IS-5AC-US with the horn attached?

With the horn installed the unit measures 5.91" x 6.85" x 6.85" and weighs 1.60 lbs.

How is the IS-5AC-US powered and which PoE wiring pairs must the injector use?

It uses a 24V 0.5A Gigabit PoE adapter with passive PoE on pairs 4,5+ and 7,8 return.
