Ubiquiti Networks
Ubiquiti Networks airCube Home ACB-AC Access Point
Dual-band Wi-Fi 5 access point with four Gigabit Ethernet ports and 24 V PoE passthrough for airMAX CPE devices
- ColorWhite
- WiFi GenerationWi-Fi 5
- Wireless Data RatesAC1350
- Security64-Bit WEP
- AntennaDual Band Antenna
- Mounting LocationIndoor
- Dual-band Wi-Fi 5 reaches 300 Mbps on 2.4 GHz and 866.7 Mbps on 5 GHz
- Four Gigabit Ethernet ports plus 24 V PoE passthrough powers a CPE device
- Remote management via UISP desktop and mobile apps
- Compact 3.46" x 3.52" x 3.51" design fits any indoor space
- Operates from -10 °C to 50 °C with 5 % to 95 % humidity
Home Wi-Fi access point with PoE passthrough
The airCube Home ACB-AC is a dual-band wireless access point built for residential use. It connects to an existing network and extends Wi-Fi 5 coverage throughout the home. Four Gigabit Ethernet ports allow wired devices to join the same LAN. The unit is managed remotely through the UISP platform.
AC1350 dual-band capacity and 24 V power limits
The 2.4 GHz radio delivers up to 300 Mbps while the 5 GHz radio reaches 866.7 Mbps. Combined throughput is rated at AC1350. The device draws a maximum of 8.5 W and accepts 24 V DC at 0.83 A or passive PoE on LAN port 1. It operates between -10 °C and 50 °C with humidity up to 95 %.
24 V PoE passthrough and UISP mobile app
A 24 V PoE output on LAN port 1 powers a compatible airMAX CPE without a separate injector. The included power adapter supplies the unit when PoE is unavailable. The UNMS mobile application for iOS and Android handles installation, configuration and ongoing monitoring from a smartphone.
Highlights
- Dual-band Wi-Fi 5 reaches 300 Mbps on 2.4 GHz and 866.7 Mbps on 5 GHz
- Four Gigabit Ethernet ports plus 24 V PoE passthrough powers a CPE device
- Remote management via UISP desktop and mobile apps
- Compact 3.46" x 3.52" x 3.51" design fits any indoor space
- Operates from -10 °C to 50 °C with 5 % to 95 % humidity
Specifications
| Brand | Ubiquiti Networks |
|---|---|
| Model | airCube Home WiFi AP |
| Part Number | ACB-AC-US |
| Color | White |
| WiFi Generation | Wi-Fi 5 |
| Wireless Data Rates | AC1350 |
| Security | 64-Bit WEP |
| Antenna | Dual Band Antenna |
| Mounting Location | Indoor |
| Interface | 4 x Gigabit Ethernet Ports |
| LEDs | Status |
| LAN Ports | 5 x 10/100/1000M |
| MIMO | router |
| Power Supply | Power Supply: 24V DC Power Method: 24V DC, 0.83A or PoE 24V In on LAN Port 1 Supported Power Voltage: 22-26V Max. Power Consumption: 8.5W |
| Certifications | SWX-ACBAC, has_fcc_id |
| Compliance | has_fcc_id, SWX-ACBAC, not_applicable |
| Temperature | Operating Temperature: -10 ~ 50 degree Celsius (-14 ~ 122 degree Fahrenheit) |
| Humidity | Operating Humidity: 5% ~ 95% non-condensing |
| Dimensions | 3.46" x 3.52" x 3.51" |
| Weight | 0.62 lb. |
| Features | PoE Passthrough for Powering a 24V CPE Device Managed by UNMS, Ubiquiti Network Management System UNMS App for Fast Setup from a Mobile Device |
| Package Contents | router |
| Disclaimer | has_fcc_id, SWX-ACBAC |
| Shipping weight | 0.52 kg |
| Package size | 147 × 127 × 109 mm |
Questions about this item
Will the airCube Home ACB-AC pass PoE power to my older airMAX CPE through its LAN port?
Yes, the unit provides 24 V PoE passthrough on LAN port 1 so a compatible airMAX CPE can be powered directly from the access point.
Which LED indicates the ACB-AC is operating normally after I mount it?
The single Status LED shows the operating state; a steady light means the access point is powered and functioning as intended.
Does the box include the 24 V DC power adapter or must I buy it separately?
The 24 V DC, 0.83 A power adapter is included, so no separate purchase is required for standard operation.
