Black weatherproof outdoor enclosure with PoE and solar inputs

Tycon Power Systems

Tycon Power Systems UPS-PL1248-18 12V 17Ah 48V PoE solar backup

SKU CH-E2ZX-51P33

Outdoor PoE backup enclosure with 12V 17Ah battery, 48V 30W PoE output, 12V 18W DC output and 140W solar input

  • ColorBlack
  • Solar-ready charging extends runtime with up to 140W panel input
  • Weatherproof UV-resistant enclosure protects gear in outdoor conditions
  • PoE input isolates connected devices from damaging power line surges
  • Integrated charge controller prevents battery overcharge and over-discharge
  • 48W total output powers PoE devices at 30W plus 12V accessories at 18W

Outdoor PoE backup system

The Tycon UPS-PL1248-18 is a solar-ready outdoor enclosure that delivers uninterrupted 48V PoE power to wireless base stations, surveillance cameras and remote sensors. It accepts PoE input over CAT5 cable and an optional 12V solar panel up to 140W, with solar taking precedence when available. The integrated 12V 17Ah AGM battery isolates connected equipment from damaging power-line surges while providing continuous backup power.

Passive cooling with surge isolation

The sealed weatherproof and UV-resistant enclosure operates without active cooling, relying on its rugged construction to dissipate heat in outdoor environments. Battery charge controllers protect against over-charge and over-discharge, while the internal electronics draw from stored battery energy rather than direct line power. This topology eliminates surge exposure and keeps acoustic signature at zero during normal operation.

Pole or wall mount with dual power outputs

The unit mounts on a pole or wall and provides both a 48V PoE output rated at 30W and an unregulated 12V terminal output rated at 18W for auxiliary devices. A single CAT5 run carries data and PoE input to the RJ45 data/PoE input port, while the RJ45 data/PoE output connects the powered device. Generous interior space allows installers to house additional customer electronics inside the same weatherproof enclosure.

Highlights

  • Solar-ready charging extends runtime with up to 140W panel input
  • Weatherproof UV-resistant enclosure protects gear in outdoor conditions
  • PoE input isolates connected devices from damaging power line surges
  • Integrated charge controller prevents battery overcharge and over-discharge
  • 48W total output powers PoE devices at 30W plus 12V accessories at 18W

Specifications

BrandTycon Power
ModelUPS-PL1248-18
ColorBlack

Questions about this item

How do I connect the solar panel and PoE inserter to the UPS-PL1248-18 enclosure?

Mount the weatherproof enclosure outdoors. Run the CAT5 cable from the included high-power PoE inserter to the RJ45 DATA/PoE input port. Connect an external 12VDC solar panel up to 140W to the solar input terminals. The charge controller manages both sources, with solar taking precedence when available.

When will the internal 12V 17Ah AGM batteries need replacement?

The valve-regulated sealed lead-acid AGM batteries typically last three to five years in outdoor standby use. The integrated charge controller protects against overcharge and over-discharge to maximise lifespan. Plan replacement when runtime drops below your required backup window for the 48W total load.

What is the maximum continuous power the UPS-PL1248-18 can deliver before voltage drops?

The system supplies up to 48W total: 30W via the PoE output and 18W from the unregulated 12VDC terminal. Sustained loads above this limit will cause the battery to discharge faster than the PoE or solar inputs can replenish it.
