Compact PoE splitter with short RJ45 and barrel cables

Tycon Power Systems

Tycon Power Systems POE-MSPLT-4805 48V 802.3af/at PoE Splitter 5V 12W

SKU CH-WZ3K-WTGCF

Converts 48V 802.3af/at PoE into regulated 5V 12W DC via 5.5 mm 2.1 mm barrel connector with data pass-through on RJ45

  • Converts 48V PoE to regulated 5V DC output
  • Delivers up to 12W power with 2.4A current capacity
  • Supports IEEE 802.3af/at PoE standards for broad compatibility
  • Isolated input and output with short-circuit and overload protection
  • Compact adapter with 5.5mm barrel and RJ45 connectors on 6in cables

Compact PoE Splitter for 5 V Devices

The Tycon Power Systems POE-MSPLT-4805 converts an active IEEE 802.3af/at 48 V PoE input into a regulated 5 V DC supply. It delivers up to 12 W continuous output with a 5.5 mm × 2.1 mm barrel connector and passes data through a dedicated RJ-45 port on six-inch cables. Short-circuit and over-current protection are built in.

Ideal for Low-Power 5 V Gear; Not for Other Voltages

Installers powering 5 V cameras, sensors, or wireless access points from a PoE switch will find the 2.4 A output a direct match. It is not for devices that require 12 V or any voltage other than 5 V, nor for applications that exceed the 12 W regulated output or the 15 W input ceiling.

5 V 2.4 A Regulated Output on Barrel Connector

The single specification that decides fit is the fixed 5 V DC output at 2.4 A provided on a 5.5 mm × 2.1 mm barrel plug. If the target device needs a different voltage, a higher current, or a different connector type, this splitter will not work.

Highlights

  • Converts 48V PoE to regulated 5V DC output
  • Delivers up to 12W power with 2.4A current capacity
  • Supports IEEE 802.3af/at PoE standards for broad compatibility
  • Isolated input and output with short-circuit and overload protection
  • Compact adapter with 5.5mm barrel and RJ45 connectors on 6in cables

Specifications

BrandTycon Power Systems

Questions about this item

What PoE standard and voltage must my switch or injector provide for the POE-MSPLT-4805 to operate?

The splitter requires an active IEEE 802.3af/at PoE input at 48 VDC to power the 5 VDC output.

Can I keep my existing 10/100 Mbps Ethernet cabling when I add this splitter?

Yes, the data path supports 10/100 MB Ethernet speeds so your current Cat5 or Cat5e runs will work unchanged.

How can I confirm the splitter is delivering the correct 5 VDC after installation?

Measure 5 VDC at the 5.5 mm × 2.1 mm barrel connector with a multimeter; the regulated output should be present when the PoE link is active.
