Turck
Turck BI5-M18-Y1X-H1141 40152 Inductive sensor M18 8.2 VDC M12
M18 inductive sensor with NAMUR output, 8.2 VDC supply and M12 connector for flush mounting
- TypeTest Equipment
- Item Count1 pack
- Selling UnitBox
- Parts3 Years
- Labor1 Year
- Flush mounting enables reliable detection in tight spaces
- Chrome-plated brass housing resists corrosion in harsh environments
- NAMUR output compliant with DIN EN 60947-5-6 for safe signalling
- M12 male connector allows quick, secure cable connection
- ATEX and SIL2 approvals support use in hazardous areas
Industrial M18 inductive sensor
The Turck BI5-M18-Y1X-H1141 is a flush-mount inductive sensor with a threaded M18 × 1 barrel. It operates on a nominal 8.2 VDC supply and provides a NAMUR output compliant with DIN EN 60947-5-6. The unit is built for hazardous-area use, carrying ATEX approvals for gas and dust zones as well as SIL2 and PLc functional-safety ratings.
Chrome-plated brass housing and M12 connector
The sensor body is made from chrome-plated brass (CuZn) for corrosion resistance in harsh environments. An M12 × 1 male connector provides a secure, tool-free electrical connection that simplifies installation and replacement in the field. The two-wire DC design reduces cabling effort compared with three-wire alternatives.
5 mm rated switching distance
The sensor detects metal targets at a rated switching distance of 5 mm when mounted flush in metal. This sensing range determines whether the device fits the required detection gap in a given machine or safety application. Buyers needing a longer range or non-flush mounting should select a different model.
Highlights
- Flush mounting enables reliable detection in tight spaces
- Chrome-plated brass housing resists corrosion in harsh environments
- NAMUR output compliant with DIN EN 60947-5-6 for safe signalling
- M12 male connector allows quick, secure cable connection
- ATEX and SIL2 approvals support use in hazardous areas
Specifications
| Brand | TURCK |
|---|---|
| Model | BI5-M18-Y1X-H1141 40152 |
| Type | Test Equipment |
| Item Count | 1 pack |
| Selling Unit | Box |
| Parts | 3 Years |
| Labor | 1 Year |
Questions about this item
How often should the M18 threaded barrel and M12 connector be inspected for wear?
The sensor has no moving parts; periodic visual checks of the chrome-plated brass barrel and M12 connector for corrosion or mechanical damage are sufficient.
What limits continuous operation at the 8.2 VDC nominal supply?
The NAMUR output to DIN EN 60947-5-6 defines the current-loop signal range; exceeding the specified switching distance or supply tolerance degrades detection reliability first.
Does the 66 g housing run hot or draw extra power during all-day use?
Power dissipation is minimal at the 8.2 VDC NAMUR loop current; the metal CuZn body stays near ambient temperature and operates silently.
