Pair of small white network boxes with RJ45 and Phoenix ports

Tupavco

Tupavco TEX-100 VDSL2 Ethernet Extender Kit 100 Mbps 7000FT

SKU CH-FVWH-PAND0

Extends Ethernet up to 7000 ft over copper phone wire or network cable at 100 Mbps with plug-and-play setup

  • Transfer Rate100 Mbps
  • Extends network reach up to 7000FT over existing copper phone line
  • Delivers symmetric 100 Mbps bandwidth using VDSL2 30a profile
  • Compliant with ITU-T G.993.2 standard for reliable long-range performance
  • Plug-and-play installation requires no driver or software setup
  • Selectable CPE or CO mode via DIP switch for flexible deployment

Purpose-built extender kit

The Tupavco TEX-100 kit contains two VDSL2 transceivers that bridge a single Ethernet link over existing copper telephone wire or standard twisted-pair cable. Each unit provides one RJ45 Ethernet port and one Phoenix-style VDSL port for the long-haul segment. The pair is aimed at installers who need to push a LAN connection beyond the 100-metre limit of plain Ethernet without laying new fibre.

Distance and profile limits

The link reaches up to 7000 feet while delivering a symmetric 100 Mbps data rate when the 30a profile is selected via the on-board DIP switch. ITU-T G.993.2 compliance guarantees interoperability with other G.993.2 equipment, but the 100 Mbps ceiling means the kit cannot serve applications that demand gigabit throughput. Asymmetric profiles are also selectable for longer reach at reduced upstream speed.

Connector choices and daily use

The Phoenix connector on the VDSL side accepts solid or stranded single-pair wire without a specialised crimp tool, simplifying termination on legacy telephone runs. The RJ45 Ethernet port connects directly to a switch, router or PoE device with a standard patch cord. DIP-switch selection between CPE and CO modes lets the same hardware serve either end of the link, so spares are interchangeable. No driver or software installation is required.

Highlights

  • Extends network reach up to 7000FT over existing copper phone line
  • Delivers symmetric 100 Mbps bandwidth using VDSL2 30a profile
  • Compliant with ITU-T G.993.2 standard for reliable long-range performance
  • Plug-and-play installation requires no driver or software setup
  • Selectable CPE or CO mode via DIP switch for flexible deployment

Specifications

BrandTupavco
ModelTEX-100
Transfer Rate100 Mbps

Questions about this item

How do I choose between the CPE and CO modes on the TEX-100?

Use the DIP switch to set one unit to CO (central office) and the other to CPE (customer premises); both ends must be set to opposite roles for the link to establish.

What does the 100 Mbps symmetric rate mean for actual throughput on a 7000 ft copper run?

The VDSL2 30a profile delivers up to 100 Mbps downstream and upstream simultaneously at maximum distance, assuming good-quality single-pair wiring.

How does the ITU-T G.993.2 standard limit the extender's performance?

Compliance with G.993.2 caps the link to the 30a profile's 100 Mbps symmetric ceiling and governs interoperability with other G.993.2 devices.
