Steel sprocket with black oxide finish, 17 hardened teeth, split-taper bushing, 5.95 inch outside diameter

Tritan

Tritan 80BTL17H Bushed Roller Chain Sprocket Collectible

SKU CH-82S4-Y66M9

A new 17-tooth, ANSI B 29.1 steel sprocket for single-strand 80 chain with a 1-inch pitch and hardened teeth

  • TypeBearings, V-belts & Power Transmission Equipment
  • ColorTransparent
  • 17 hardened teeth for durable chain engagement
  • ANSI B 29.1 compliant for standard power transmission
  • 95 in outside diameter fits 80 chain pitch
  • Split taper 2012 bushing allows secure mounting
  • Black oxide finish resists corrosion in industrial use

Industrial Sprocket for Chain Drive Systems

This new Tritan 80BTL17H bushed roller chain sprocket is built for single-strand ANSI 80 chain with a one-inch pitch. It suits maintenance engineers and original-equipment assemblers who need a hardened-tooth steel sprocket that matches the 5.442-inch pitch diameter and 17-tooth count specified for their drive layout.

Split-Taper Bushing Mount Simplifies Fitting

The sprocket accepts a 2012 split-taper bushing with a maximum bore of two inches, so no keyway machining is required on the shaft. Alignment issues usually arise when the bushing bolts are not tightened in a star pattern to the maker’s torque value, causing eccentric run-out and accelerated chain wear.

ANSI B 29.1 Standard Defines Interchange Limits

The sprocket conforms to ANSI B 29.1, fixing the tooth profile, 0.575-inch tooth width and 5.95-inch outside diameter. Drives that demand a different chain number, multi-strand width or a pitch diameter outside 5.442 inches cannot use this sprocket without redesigning the entire drive train.

Highlights

  • 17 hardened teeth for durable chain engagement
  • ANSI B 29.1 compliant for standard power transmission
  • 95 in outside diameter fits 80 chain pitch
  • Split taper 2012 bushing allows secure mounting
  • Black oxide finish resists corrosion in industrial use

Specifications

BrandTRITAN
TypeBearings, V-belts & Power Transmission Equipment
ColorTransparent

Questions about this item

How can I confirm the sprocket is working correctly after installation?

Verify smooth chain engagement on all 17 hardened teeth, check for no binding at the 5.442 in pitch diameter, and ensure the 0.575 in tooth width matches the chain.

What comes in the box and what must be purchased separately?

The sprocket with black oxide finish, 3 5/8 in hub diameter and 0.675 in hub projection is included; the 2012 split taper bushing is sold separately.

Which chain pitch and tooth count combination should I select for my drive?

Choose this model when your drive uses ANSI B 29.1 chain number 80 with 1 in pitch and requires a 17 tooth sprocket for a single strand.
