Transparent angular bearing, 35 mm bore, double shielded, 72 mm outer diameter, 27 mm wide

Tritan

Tritan 5207 ZZ/C3 PRX Angular Bearing 35 mm Bore

SKU CH-3F9B-8V3YZ

Angular contact ball bearing with 35 mm bore, 72 mm outside diameter and 27 mm width, double-shielded and rated to 7,400 RPM

  • TypeBearings, V-belts & Power Transmission Equipment
  • ColorTransparent
  • Precision alignment from 35 mm bore and 72 mm outer diameter
  • High-speed capability up to 7,400 RPM for demanding applications
  • Wide temperature range from -40 °C to 175 °C suits harsh environments
  • Double-shielded design with polyamide cage retains SRI 2 and Polyrex EM grease
  • Two-row angular contact construction handles combined radial and axial loads

Angular Contact Ball Bearing 35 mm Bore

This is a new TRITAN angular contact ball bearing with a 35 mm bore and 72 mm outside diameter. It uses alloy steel rings and balls with a polyamide cage. The double-shielded unit comes lubricated with SRI 2 and Polyrex EM grease. It suits machinery requiring precise axial load handling.

Sustained Load Performance

The bearing operates continuously up to 7,400 RPM across a temperature range of -40 to 175 degrees C. Two rows of balls distribute combined radial and axial forces evenly during extended runs. Factory grease fill resists breakdown at the upper temperature limit. The unmatched single-row design simplifies replacement scheduling.

Build Quality and Mounting

Double shields protect the raceways from contaminants while retaining lubricant in dusty environments. Polyamide cage material reduces weight and running noise compared with metal alternatives. The 27 mm overall width fits standard housings for the 3207/5207 series. Transparent finish allows quick visual inspection of shield condition.

Highlights

  • Precision alignment from 35 mm bore and 72 mm outer diameter
  • High-speed capability up to 7,400 RPM for demanding applications
  • Wide temperature range from -40 °C to 175 °C suits harsh environments
  • Double-shielded design with polyamide cage retains SRI 2 and Polyrex EM grease
  • Two-row angular contact construction handles combined radial and axial loads

Specifications

BrandTRITAN
TypeBearings, V-belts & Power Transmission Equipment
ColorTransparent

Questions about this item

How much heat can the 5207 angular bearing handle during continuous operation?

The bearing is rated for a maximum operating temperature of 175 degrees C and a minimum of -40 degrees C, with SRI 2 and Polyrex EM grease lubrication.

What shaft size is required to install this 35 mm bore bearing?

This bearing requires a shaft with a 35 mm diameter to match its bore size for proper fitment.

Will the 72 mm outside diameter fit standard housings used with older 3207 series bearings?

Yes, the 72 mm outside diameter and 27 mm width match the 3207/5207 industry standard dimensions for direct interchangeability.
