Small transparent double-sealed angular contact ball bearing

Tritan

Tritan 5200 2RS/C3 PRX Angular Contact Ball Bearing 850lb collectible

SKU CH-0F38-8JTEB

Angular contact ball bearing with 10 mm bore, 30 mm outside diameter and 14.3 mm width rated for 850 lb load capacity

  • TypeBearings, V-belts & Power Transmission Equipment
  • ColorTransparent
  • Angular contact design handles combined radial and axial loads
  • Double-sealed closure keeps lubricant in and contaminants out
  • Polyamide cage reduces friction for 19000 RPM capability
  • Alloy steel rings and balls withstand 175 °C operating temperature
  • 850 lb load rating suits demanding power-transmission applications

Angular Contact Bearing 5200

The Tritan 5200 is a new angular contact ball bearing designed for precision rotary applications. It suits engineers and maintenance teams who need a sealed, high-speed rolling element with a defined load rating. The bearing uses alloy steel balls and rings with a polyamide cage for smooth operation.

850 lb Capacity and 19 000 RPM Limit

The bearing carries a dynamic load rating of 850 lb and is rated for a maximum speed of 19 000 RPM. It operates continuously between -40 and 175 degrees Celsius thanks to SRI 2 and Polyrex EM grease fill. The double-sealed closure retains lubricant and excludes contamination, but the single-row, unmatched design limits axial load to one direction only.

10 mm Bore and 30 mm Outside Diameter

The bearing fits a 10 mm shaft and seats in a 30 mm housing bore with an overall width of 14.3 mm. The polyamide cage and double seals require no external lubrication lines, freeing up space in compact assemblies. It is not suited for applications needing matched pair sets or bi-directional heavy thrust loads.

Highlights

  • Angular contact design handles combined radial and axial loads
  • Double-sealed closure keeps lubricant in and contaminants out
  • Polyamide cage reduces friction for 19000 RPM capability
  • Alloy steel rings and balls withstand 175 °C operating temperature
  • 850 lb load rating suits demanding power-transmission applications

Specifications

BrandTRITAN
TypeBearings, V-belts & Power Transmission Equipment
ColorTransparent

Questions about this item

Will the 10 mm bore fit the shaft on my older 5200-series housing?

The bearing has a 10 mm bore and 30 mm outside diameter, so it matches the standard 5200 envelope; verify your shaft tolerance before installing.

How can I confirm the double seals are seating correctly after installation?

Rotate the inner ring by hand — it should turn smoothly with light resistance from the SRI 2 and Polyrex EM grease fill and no audible grinding.

Does the box include a retaining ring or must I supply my own?

The package contains the single angular-contact bearing only; snap rings, circlips or mounting hardware are not included.
