Tripp Lite
Tripp Lite B005-HUA2-K 2-Port HDMI/USB KVM Switch 4K 60 Hz
A 2-port KVM switch that shares one HDMI monitor, keyboard, mouse and USB 3.0 peripherals between two computers at 4K 60 Hz with HDR and IR remote control
- TypeHDMI, USB
- PC Connectors4 x 3.5mm 2 x HDMI 2 x USB 3.0 Type-B
- Console Connectors4 x 3.5mm 1 x HDMI 2 x USB-A 3.0 2 x USB-A 2.0
- Computer Connections2 Port HDMI
- Monitor Connections1 Port
- Video Resolution4K x 2K (4096 x 2160) @ 60 Hz
- Switch two HDMI computers with one monitor and keyboard
- View 4096 x 2160 resolution at 60 Hz for sharp video
- Share USB 3.0 peripherals across both connected systems
- Toggle sources via push buttons, hotkeys, mouse or IR remote
- Operate reliably from 32 to 113 °F ambient temperature
Two-Port HDMI KVM Switch
This Tripp Lite B005-HUA2-K lets you control two HDMI-enabled desktops or notebooks from a single HDMI monitor, USB keyboard and mouse. It supports video resolutions up to 4096 x 2160 at 60 Hz with HDR and HDCP 2.2 pass-through. Two USB 3.0 hub ports allow peripheral sharing between the connected computers. Switching is handled by front push buttons, hotkeys, mouse gestures or the included IR remote.
Check Your Computer Ports
Verify that each source computer provides an HDMI video output and a USB 3.0 Type-B port for the KVM link cables. The switch requires a free HDMI input on your monitor and two USB-A ports for keyboard and mouse. An external power supply is included and must be connected; the unit draws 0.6 A from a 100-240 V 50/60 Hz mains supply. Ensure your operating system supports standard USB HID switching — Windows, macOS and Linux are supported.
Replaces Dual-Monitor Keyboard Mouse Sets
This unit replaces the need for two separate monitor, keyboard and mouse sets on a crowded desk. The upgrade is worthwhile when you regularly work across two computers and want instant switching without unplugging cables. It also consolidates USB 3.0 peripherals such as drives or printers so they are accessible from either system. Buyers who need to control more than two computers or who require DisplayPort or USB-C video inputs should look for a larger or differently equipped switch.
Highlights
- Switch two HDMI computers with one monitor and keyboard
- View 4096 x 2160 resolution at 60 Hz for sharp video
- Share USB 3.0 peripherals across both connected systems
- Toggle sources via push buttons, hotkeys, mouse or IR remote
- Operate reliably from 32 to 113 °F ambient temperature
Specifications
| Brand | TRIPP LITE |
|---|---|
| Model | B005-HUA2-K |
| Type | HDMI, USB |
| PC Connectors | 4 x 3.5mm 2 x HDMI 2 x USB 3.0 Type-B |
| Console Connectors | 4 x 3.5mm 1 x HDMI 2 x USB-A 3.0 2 x USB-A 2.0 |
| Computer Connections | 2 Port HDMI |
| Monitor Connections | 1 Port |
| Video Resolution | 4K x 2K (4096 x 2160) @ 60 Hz |
| PC Selection | Hotkey; Mouse; Pushbutton; Remote Selector |
| Temperature | 32 to 113° (0 to 45°C) |
| Humidity | 10% to 85% RH (No Condensation) |
| Power Features | 100-240V, 50/60Hz, 0.6A |
| USB Features | USB 2.0 (up to 480 Mbps); USB 3.0 (up to 5 Gbps); USB 3.1 Gen 1 (up to 5 Gbps) |
| Features | Controls 2 HDMI-enabled desktop or notebook computers using one centralized HDMI monitor and USB keyboard/mouse. Supports 4K @ 60 Hz video resolutions as specified in HDMI 2.0 Carries High Dynamic Range (HDR) signals for expanded color accuracy Dual USB 3.0 hub ports let you share USB peripherals among connected computers Push buttons, hotkeys and included IR remote allow easy toggling between computers Supports all major operating systems, including Windows, macOS and Linux |
| Dimensions | 1.02" x 9.57" x 2.95" |
| Weight | 1.11 lbs. |
| Package Contents | B005-HUA2-K 2-Port HDMI/USB KVM Switch IR extender IR remote control 2 x USB 3.0 A-to-B cables (M/M) External power supply (Input: 100–240V, 50/60 Hz, 0.5A; Output: 5V 3A) Mounting brackets Owner’s manual |
| Shipping weight | 0.91 kg |
| Package size | 254 × 102 × 76 mm |
Questions about this item
What cables and accessories come with the B005-HUA2-K and do I need to buy HDMI cables separately?
The package includes the KVM switch, IR extender, IR remote, two USB 3.0 A-to-B cables, an external 5 V 3 A power supply, mounting brackets and the owner's manual. HDMI cables are not included and must be purchased separately.
How do the two USB 3.0 hub ports and the two USB 2.0 ports differ for sharing peripherals?
The two USB 3.0 Type-A ports support up to 5 Gbps for high-speed devices such as external drives, while the two USB 2.0 Type-A ports operate at up to 480 Mbps and are suited for keyboards, mice or other low-bandwidth peripherals.
What does the 4096 x 2160 at 60 Hz rating mean for my monitor and computers?
It means the switch can pass a true 4K 60 Hz 4:4:4 signal with HDR and HDCP 2.2 from either connected computer to a single HDMI monitor without downscaling or frame-rate loss.
