TRENDnet VC-801UK-L 8 Port USB VGA KVM Switch
Controls eight computers from one VGA monitor, USB keyboard and mouse using push buttons or a wired desktop selector, with eight 2-in-1 cables included
- TypeUSB
- PC ConnectorsVga
- Console ConnectorsVga
- Computer ConnectionsUSB 2.0
- Monitor Connections4 Ports
- PC SelectionPush Buttons
- Control 8 computers from one USB keyboard, mouse and VGA monitor
- Two switching methods: front-panel push buttons or 2 m wired desktop selector
- Supports Windows, Linux and Novell operating systems without extra drivers
- Eight 2-in-1 USB VGA cables included in 1.5 m and 1.8 m lengths
- Draws power from USB connections — no external power supply needed
Eight-port VGA KVM
The TRENDnet VC-801UK-L lets one USB keyboard, mouse and VGA monitor control eight computers or servers. It ships with eight 2-in-1 USB VGA cables, a wired desktop selector and push-button switching on the front panel. The unit fits a standard 1U 19-inch rack and draws power from the connected USB ports. No external power supply is required.
Rackmount integration
The switch occupies a single rack unit measuring 14.33in wide by 12.83in high by 9.06in deep. Eight VGA and USB 2.0 cables connect the rear ports to each host system. A console VGA port and USB keyboard and mouse ports sit on the front for local access. The wired desktop selector provides a second switching method without leaving the workstation.
Sustained operation
Passive power from the USB 2.0 links keeps the switch running continuously without a dedicated adapter. Video supports resolutions up to 1920x1440 at 60Hz with VGA DDC, DDC2 and DDC2B compatibility. Audio and microphone signals switch alongside the video and USB channels. The design targets server rooms and multi-PC workstations needing reliable, long-term switching.
Highlights
- Control 8 computers from one USB keyboard, mouse and VGA monitor
- Two switching methods: front-panel push buttons or 2 m wired desktop selector
- Supports Windows, Linux and Novell operating systems without extra drivers
- Eight 2-in-1 USB VGA cables included in 1.5 m and 1.8 m lengths
- Draws power from USB connections — no external power supply needed
Specifications
| Brand | TRENDnet |
|---|---|
| Series | 8 port KVM VGA |
| Model | VC-801UK-L |
| Part Number | VC-801UK-L |
| Type | USB |
| PC Connectors | Vga |
| Console Connectors | Vga |
| Computer Connections | USB 2.0 |
| Monitor Connections | 4 Ports |
| PC Selection | Push Buttons |
| Monitors Supported | VGA DDC, DDC2, DDC2B |
| Audio Features | Offers audio and microphone switching |
| Power Features | Requires no additional power supply |
| USB Features | with USB support |
| SplitterOnly | VGA Monitor Splitter only |
| Application | Vga, Usb, remote |
| Features | Vga, Usb, remote, 8, IP56, Push Button |
| Dimensions | 14.33in W x 12.83in H x 9.06in D |
Questions about this item
What is the maximum VGA resolution the VC-801UK-L can sustain when all eight ports are active?
The switch supports up to 1920 x 1440 at 60 Hz on its single VGA console output.
How much heat or fan noise does the unit produce during continuous 24-hour operation?
It requires no external power supply and has no fan, so it runs silently with negligible heat output.
Which cables or adapters must I already have to connect eight computers right out of the box?
Eight 2-in-1 USB VGA KVM cables (four 1.5 m and four 1.8 m) are included, so no extra cables are needed.
