Small rectangular metal network switch with five RJ45 ports and status LEDs

TRENDnet

TRENDnet TEG-S50G 5-Port Gigabit GREENnet Switch

SKU CH-HHMS-0EEB0

A compact five-port Gigabit switch with GREENnet energy saving and a 10 Gbps switching fabric

  • StandardsIEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
  • Network Management TypeUnmanaged
  • Primary Ports5 x RJ45
  • Primary Port Speed10/100/1000Mbps
  • Switching MethodStore and Forward
  • Jumbo Frames9216bytes
  • GREENnet technology cuts power use by up to 70%
  • Five Gigabit RJ45 ports deliver 1000 Mbps wired speed
  • 10 Gbps switching fabric handles heavy traffic loads
  • 104 KB buffer memory smooths bursty data flows
  • Sturdy metal housing fits in 6.7" x 3.86" x 1.1" space

Compact Gigabit Switch for Small Networks

The TRENDnet TEG-S50G is a five-port unmanaged Gigabit switch built for home offices or small workgroups that need simple wired expansion. Its metal housing and GREENnet technology cut power use by up to 70 percent while delivering a total switching fabric of 10Gbps. Plug-and-play operation means no configuration is required.

Check Cabling and Power Before Installing

Verify that your devices use RJ45 connectors and support 10/100/1000Mbps speeds to match the switch ports. The unit requires the included 7.5V DC external adapter, so confirm an outlet is available near the mounting location. Ensure cables are Category 5e or better to achieve full Gigabit throughput.

Low Heat and Silent Operation

With no moving parts the switch runs completely silent in normal use. GREENnet technology adjusts voltage per port, keeping the chassis cool across the 0°C to 40°C operating range. The 104KByte buffer and store-and-forward switching maintain steady throughput without generating excess heat.

Highlights

  • GREENnet technology cuts power use by up to 70%
  • Five Gigabit RJ45 ports deliver 1000 Mbps wired speed
  • 10 Gbps switching fabric handles heavy traffic loads
  • 104 KB buffer memory smooths bursty data flows
  • Sturdy metal housing fits in 6.7" x 3.86" x 1.1" space

Specifications

BrandTRENDnet
ModelTEG-S50G
StandardsIEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
Network Management TypeUnmanaged
Primary Ports5 x RJ45
Primary Port Speed10/100/1000Mbps
Switching MethodStore and Forward
Jumbo Frames9216bytes
Buffer Memory104KBytes
ProtocolsCSMA/CD
TopologyStar
LEDsPower, Link/ACT, 100Mbps, 1000Mbps
Power7.5V DC, 1A external power adapter
Dimensions6.7" x 3.86" x1.1"
Weight15.2 oz.
Temperature0°C to 40°C (32°F to 104°F)
Humidity5% - 90%, Non-condensing
FeaturesSwitch Fabric: 10Gbps Forwarding Capacity
Filtering Table: Filtering Table
Back pressure Flow Control for half-duplex mode
Operates and maximizes packet filtering and forwarding rate
Sturdy metal housing
Diagnostic LEDs and Plug & Play
Package ContentsTEG-S50g
Multi-Language Quick Installation Guide

Questions about this item

What comes in the box with the TEG-S50G and do I need to buy any cables separately?

The package includes the switch and a multi-language quick installation guide. Ethernet cables are not included and must be purchased separately.

Which version of the TEG-S50G should I choose for a small office needing five wired connections?

This model provides five RJ45 ports operating at 10/100/1000Mbps with a 10Gbps switching fabric, suitable for connecting five devices at Gigabit speed.

What does the 10Gbps switching fabric mean for actual throughput on my network?

The 10Gbps fabric represents total non-blocking bandwidth across all five ports running full-duplex at 1000Mbps each, allowing simultaneous traffic without congestion.
