TRENDnet A301 USB 3.0 KVM Switch 2-Port 4K@60Hz
Share four USB 3.0 peripherals and one 4K@60 Hz HDMI monitor between two computers using push-button switching with LED status indicators
- TypeUSB
- PC ConnectorsUsb, Hdmi
- Console ConnectorsUsb, Hdmi
- Computer ConnectionsUSB 2.0
- Monitor Connections4 Ports
- PC SelectionPush Buttons
- Share 4 USB devices and 1 HDMI monitor between two computers
- Switch computers with one button press and see active system via LED
- Transfer data up to 5Gbps with four USB 3.0 ports
- View 4K resolution at 60Hz or 1440p at 120Hz on connected display
- Includes two 1.2 m USB and two 1.2 m HDMI cables for immediate setup
Two-computer KVM switch
The TRENDnet A301 lets two computers share one HDMI monitor and four USB 3.0 peripherals. Push-button switching with red and blue LEDs shows the active system at a glance. No driver installation is required on Windows, Mac OS, Linux or Chrome OS. The bundle includes two 1.2 m USB 3.0 cables and two 1.2 m HDMI cables.
Built-in cables and optional power
Integrated 1.2 m cables reduce desk clutter and eliminate repeated plugging and unplugging. Four USB-A 3.0 ports deliver up to 5 Gbps data transfer for printers, scanners, drives or input devices. A DC 5 V USB-C power jack can be used when high-draw devices such as external hard drives need extra current. Non-slip pads keep the unit stable on the desktop.
Check monitor resolution and cable reach
The HDMI output supports up to 4K at 60 Hz, with 4K at 30 Hz and 2560×1440 at 120 Hz also available. Verify that your monitor and both computers can drive the desired resolution over HDMI. The fixed 1.2 m cable length limits placement distance between the switch and each computer. Buyers needing longer runs or additional monitor outputs should consider other solutions.
Highlights
- Share 4 USB devices and 1 HDMI monitor between two computers
- Switch computers with one button press and see active system via LED
- Transfer data up to 5Gbps with four USB 3.0 ports
- View 4K resolution at 60Hz or 1440p at 120Hz on connected display
- Includes two 1.2 m USB and two 1.2 m HDMI cables for immediate setup
Specifications
| Brand | TRENDnet |
|---|---|
| Series | USB HDMI Switch |
| Model | A301 |
| Part Number | A301 |
| Type | USB |
| PC Connectors | Usb, Hdmi |
| Console Connectors | Usb, Hdmi |
| Computer Connections | USB 2.0 |
| Monitor Connections | 4 Ports |
| PC Selection | Push Buttons |
| Monitors Supported | VGA DDC, DDC2, DDC2B |
| Audio Features | Offers audio and microphone switching |
| USB Features | with USB support |
| SplitterOnly | VGA Monitor Splitter only |
| Application | Usb, Hdmi, USB, push_button |
| Features | Usb, Hdmi, USB, push_button, 2 |
| Dimensions | 14.33in W x 12.83in H x 9.06in D |
| Package Contents | with Built-in Cables |
Questions about this item
What resolution does the HDMI port support at 60 Hz?
The HDMI port supports up to 4K at 60 Hz, and also handles 4K at 30 Hz or 2560×1440 at 120 Hz.
What cables are included and how long are they?
Two USB 3.0 cables and two HDMI cables are included, each 1.2 m (4 ft) long.
How do I switch between the two computers and what indicates the active one?
Press the push button on the unit; a red LED means PC1 is active, a blue LED means PC2 is active.
