Compact metal box with one RJ-45 port and one duplex SC fiber port

Transition Networks

Transition Networks SGETF1013-110-NA Gigabit Ethernet media converter

SKU CH-P1NX-8CD9A MPN SGETF1013-110-NA

Converts 1000Base-T copper to 1000Base-SX multimode fiber up to 1804.5 ft with auto-negotiation and transparent link pass-through

  • TypeConsumer Electronics
  • Specifications1 x 1000BASE-T (RJ-45) [100 m/328 ft.] 1 x 1000BASE-SX 850nm
  • FeaturesAuto-Negotiation (802.3u) (Copper & Fiber) Allows devices to
  • Converts copper to fiber for longer runs
  • Auto-negotiation picks the best link mode automatically
  • Transparent Link Pass Through keeps link status visible
  • Multimode SC port reaches 1804 ft on 50/125 µm fiber
  • Compact 3.25 x 4.80 in stand-alone design

Media conversion for Gigabit Ethernet

The Transition Networks SGETF1013-110-NA converts a 1000BASE-T copper link to a 1000BASE-SX 850 nm multimode fibre link. It suits installers who need to extend a Gigabit connection beyond the 100 m copper limit using existing multimode cabling.

Silent operation with no moving parts

The stand-alone unit has no fans and draws power from an external supply, so it adds no audible noise to the rack or wall mount. Auto-negotiation on both the RJ-45 and SC interfaces selects the optimum duplex mode without manual configuration.

Compact metal enclosure with SC duplex port

The housing measures 1 in high, 3.25 in wide and 4.80 in deep, fitting easily on a shelf or DIN rail clip. A single SC duplex connector handles transmit and receive fibres, while the RJ-45 port accepts shielded or unshielded twisted-pair cable up to 100 m.

Highlights

  • Converts copper to fiber for longer runs
  • Auto-negotiation picks the best link mode automatically
  • Transparent Link Pass Through keeps link status visible
  • Multimode SC port reaches 1804 ft on 50/125 µm fiber
  • Compact 3.25 x 4.80 in stand-alone design

Specifications

BrandTransition Networks
ModelSGETF1013-110-NA
TypeConsumer Electronics
Specifications1 x 1000BASE-T (RJ-45) [100 m/328 ft.]
1 x 1000BASE-SX 850nm multimode (SC) [62.5/125µm: 220 m/722 ft.; 50/125µm: 550 m/1804 ft.]
FeaturesAuto-Negotiation (802.3u) (Copper & Fiber)
Allows devices to perform automatic configuration to achieve the best possible mode of operation over a link.
Transparent Link Pass Through
Transparent Link Pass Through sends a link-loss signal over the fiber, instructing the remote converter to shut down the copper port—thus notifying the end device—while maintaining the fiber link between the two converters.
Automatic Link Restoration
Transition Networks's converters will automatically re-establish link in all network conditions.
Pause (IEEE 802.3xy)
Pause signaling is an IEEE feature tha
Shipping weight0.68 kg
Package size178 × 140 × 89 mm

Questions about this item

How do I install the SGETF1013-110-NA media converter, and what step do people often miss?

Connect the 1000BASE-T RJ-45 port to copper cable up to 100 m and the 1000BASE-SX SC duplex port to multimode fibre; the step often missed is enabling Auto-Negotiation on both linked devices so the link passes through transparently.

What maintenance or replacement will the SGETF1013-110-NA need later?

The unit has no moving parts or user-replaceable modules; maintenance is limited to keeping the SC connectors clean and verifying the fibre patch cords (62.5/125 µm or 50/125 µm) remain undamaged.

What limit appears first on the SGETF1013-110-NA under sustained use?

The fibre distance limit is reached first: 220 m on 62.5/125 µm multimode or 550 m on 50/125 µm multimode at 850 nm, while the copper side supports 100 m.
