Silver 1U rackmount switch with forty-eight RJ45 ports and four SFP+ slots on the front

TP-Link

TP-Link TL-SG3452XP 48-port PoE+ managed network switch

SKU CH-HX89-BE8M3 MPN TL-SG3452XP

Managed L2+ switch with 48 PoE+ gigabit ports and four 10 Gbps SFP+ uplinks, 500 W power budget

  • FormatRackmount
  • Network Management TypeManaged
  • Primary Ports48 x RJ45 + 4 x SFP+
  • Primary Port Speed10/100/1000Mbps + 10 Gbps
  • Primary Port Type48 x 10/100/1000 Mbps RJ45 PoE+ Ports 4 x 10G SFP+ Slots 1 x
  • MAC Address Table16K
  • Four 10 Gbps SFP+ uplinks deliver high-bandwidth aggregation
  • Forty-eight PoE+ ports supply up to 30 W each for powered devices
  • 500 W total PoE budget supports dense access-point or camera deployments
  • L2+ feature set includes static routing, QoS and IGMP snooping
  • Omada SDN integration enables centralised cloud management and remote monitoring

48-Port PoE+ Managed Switch

The TP-Link TL-SG3452XP is a rackmount managed switch built for business networks that need both data and power over a single cable. It provides forty-eight gigabit RJ45 ports with PoE+ support plus four 10 Gbps SFP+ uplink slots for high-speed aggregation. The unit suits installers deploying IP cameras, wireless access points or VoIP phones across a single rack.

500 W PoE+ Power Budget

The switch delivers up to 30 W on each of its forty-eight PoE+ ports while staying within a total 500 W power budget. This figure decides how many high-draw devices can run simultaneously without an external injector. Ports comply with 802.3af and 802.3at standards so compatible endpoints negotiate power automatically.

Fan-Cooled 0-40 °C Operation

Active cooling keeps the chassis within its 0 to 40 °C operating range while powered from 100-240 V AC mains. The 1U rackmount form factor fits standard cabinets and the included rackmount kit secures the 17.30" x 13.00" x 1.70" enclosure. Acoustic output scales with thermal load during normal use.

Highlights

  • Four 10 Gbps SFP+ uplinks deliver high-bandwidth aggregation
  • Forty-eight PoE+ ports supply up to 30 W each for powered devices
  • 500 W total PoE budget supports dense access-point or camera deployments
  • L2+ feature set includes static routing, QoS and IGMP snooping
  • Omada SDN integration enables centralised cloud management and remote monitoring

Specifications

BrandTP-Link
ModelTL-SG3452XP
FormatRackmount
Network Management TypeManaged
Primary Ports48 x RJ45 + 4 x SFP+
Primary Port Speed10/100/1000Mbps + 10 Gbps
Primary Port Type48 x 10/100/1000 Mbps RJ45 PoE+ Ports
4 x 10G SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port
MAC Address Table16K
VLAN SupportVLAN Group
- Max 4K VLAN Groups
802.1Q Tagged VLAN
MAC VLAN: 30 Entries
Protocol VLAN: Protocol Template 16, Protocol VLAN 16
Private VLAN
GVRP
VLAN VPN (QinQ)
- Port-Based QinQ
- Selective QinQ
Voice VLAN
Jumbo Frames9KB
Buffer Memory12 Mbit
PoEStandard: 802.3at/af compliant
PoE+ Ports: 48 Ports, up to 30W per port
Power Budget: 500W
QoS8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
- SP (Strict Priority)
- WRR (Weighted Round Robin)
- SP+WRR
Bandwidth Control
- Port/Flow based Rating Limiting
Smoother Performance
Action for Flows
- Mirror (to supported interface)
- Redirect (to supported interface)
- Rate Limit
- QoS Remark
Power100-240 V AC~50/60 Hz
Dimensions17.30" x 13.00" x 1.70"
TemperatureOperating Temperature: 0 - 40 °C (32 - 104 °F)
Storage Temperature: -40 - 70 °C (-40 - 158 °F)
HumidityOperating Humidity: 10-90% RH non-condensing
Storage Humidity: 5-90% RH non-condensing
Package ContentsTL-SG3452XP Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet
Shipping weight6.58 kg
Package size533 × 432 × 102 mm

Questions about this item

What does the 500 W PoE+ budget mean when I plug in 48 devices?

The switch can deliver up to 30 W per port across all 48 ports, but the total power drawn cannot exceed 500 W, so full 30 W is only available on a subset of ports at once.

How do the four 10 Gbps SFP+ uplinks limit real-world throughput?

Each SFP+ slot accepts 10 Gbps transceivers for fibre or copper uplinks, providing non-blocking 10 Gbps links to core switches or servers without sharing bandwidth with the 48 gigabit ports.

What physical space and mounting hardware does the unit need in a rack?

The switch measures 17.30" x 13.00" x 1.70" and includes a rackmount kit for standard 1U installation, plus rubber feet for desktop use.
