Silver metal desktop switch with eight RJ45 ports and rack ears

TP-Link

TP-Link TL-SG1008MP 8-port Gigabit PoE+ network switch

SKU CH-VY32-TBT2Q MPN TL-SG1008MP

An 8-port Gigabit switch delivers up to 30W per PoE+ port with a 126W total budget for powering access points, cameras and phones over a single cable

  • Switch TypeOthers
  • FormatDesktop
  • StandardsPassive PoE
  • Network MediaRJ45
  • Network Management TypeUnmanaged
  • Uplink Ports8
  • Powers devices up to 30W per port with 126W total budget
  • Expands wired networks using single cables for power and data
  • Saves up to 75% power consumption with energy-efficient technology
  • Connects eight Gigabit devices via 10/100/1000Mbps RJ45 ports
  • Mounts on desktop or rack with included kit and rubber feet

Eight PoE+ ports for powered devices

The TL-SG1008MP is an unmanaged Gigabit switch with eight RJ45 ports that all support the PoE+ standard. It delivers both data and up to 30W per port over a single Ethernet cable, simplifying deployments of wireless access points, IP cameras and VoIP phones. A total power budget of 126W allows several high-draw devices to run simultaneously. The desktop or rack-mountable format fits common installation scenarios.

Suits small offices adding powered endpoints

This switch is designed for networks that need to power PoE+ devices without a separate injector or managed configuration. It works where a plug-and-play Gigabit uplink and 126W of PoE budget cover the current device count. Builders who require VLANs, QoS, link aggregation or a higher total PoE budget should consider a managed or higher-capacity model instead.

126 W total PoE budget decides capacity

The single figure that determines whether this unit fits the job is the 126W power budget shared across all eight ports. Add the maximum draw of every connected PoE+ device; if the sum stays at or below 126W the switch can power them all, otherwise an additional power source or a switch with a larger budget is required.

Highlights

  • Powers devices up to 30W per port with 126W total budget
  • Expands wired networks using single cables for power and data
  • Saves up to 75% power consumption with energy-efficient technology
  • Connects eight Gigabit devices via 10/100/1000Mbps RJ45 ports
  • Mounts on desktop or rack with included kit and rubber feet

Specifications

BrandTP-Link
SeriesProSafe
ModelTL-SG1008MP
Part NumberTL-SG1008MP
Switch TypeOthers
FormatDesktop
StandardsPassive PoE
Network MediaRJ45
Network Management TypeUnmanaged
Uplink Ports8
Uplink InterfaceRJ45
Uplink Speed10/100 Mbps
Uplink Speed/TypeRJ45
Primary Port Count8
Primary Ports8 x RJ45
Primary Port Speed10/100/1000Mbps
Primary Port TypeRJ45
Management InterfaceRJ45
Management FeatureTL-SG1008MP, Power Cord, Installation Guide, Rackmount Kit, Rubber Feet
MAC Address Table4K
Packet Forwarding Rate1000 megabits_per_second
Buffer Memory1.5Mbits
IPv4 Features8 Port PoE+
PoE8 Port PoE+
SNMPNo
Layer1
Layer 2 FeaturesRJ45, 1000 megabits_per_second, 8
Layer 3 FeaturesTL-SG1008MP
CablingRJ45
PoE Ports8 Port PoE+
PoE Power Budget8 Port PoE+
Power100-240VAC, 50/60Hz
Max Power Consumption:
- 9.89W(220V/50Hz. no PD connected)
- 140.67W(110V/60Hz. with 126W PD connected)
Max Power Consumption153 watts
Dimensions11.60" x 7.10" x 1.70"
Weight4.9
Certificationon_product_combined_cancer_reproductive, not_applicable
Max Heat Dissipation153 watts
TemperatureOperating Temperature: 0°C~50°C (32°F~122°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
HumidityOperating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
FeaturesCompatible With IEEE 802.3af/at Compliant power devices (PD)
Port Priority Function
MAC Address Auto-Learning And Auto-Aging
IEEE802.3x Flow Control
Package ContentsTL-SG1008MP, Power Cord, Installation Guide, Rackmount Kit, Rubber Feet
Disclaimeron_product_combined_cancer_reproductive
Shipping weight2.27 kg
Package size305 × 203 × 76 mm

Questions about this item

How often will the internal fan need cleaning on the TL-SG1008MP?

The switch uses a fanless design, so no fan maintenance is required.

What power limit is reached first when all eight PoE+ ports run at 30 W each?

The 126 W total budget caps combined draw before any single port hits its 30 W ceiling.

How much heat does the unit add to a rack when it powers four 30 W cameras all day?

With a 126 W budget the switch dissipates roughly that much heat under full PoE load.
