Black plastic PoE splitter with two RJ45 ports and a DC power output jack

TP-Link

TP-Link TL-POE10R PoE Splitter Gigabit 5/9/12V 100m

SKU CH-X51M-E19EA MPN TL-POE10R

Splits PoE into data and selectable 5V, 9V or 12V DC power over Gigabit Ethernet up to 100 metres with no configuration required

  • TypePoE Splitter
  • ColorBlack
  • SpecificationsInterface: 2 x 10/100/1000Mbps RJ45 Port AUTO Negotiation/AU
  • FeaturesIEEE 802.3af compliant Delivers power up to 100 meters Gigab
  • IEEE 802.3af compliant for reliable network power delivery
  • Gigabit ports support up to 1000 Mbps data speeds
  • Selectable 5/9/12V DC output fits varied devices
  • Plug-and-play design requires no configuration
  • Extends power and data up to 100 meters

PoE Splitter for Non-PoE Devices

The TP-Link TL-POE10R separates data and power from a single Ethernet cable to run non-PoE equipment. It accepts IEEE 802.3af input and provides selectable 5V, 9V or 12V DC output. Network managers use it to add IP cameras, wireless access points or VoIP phones where no mains socket exists.

Gigabit Ports and Plug-and-Play Setup

Two 10/100/1000 Mbps RJ45 ports handle data with auto-negotiation and auto MDI/MDIX. A single DC jack delivers the chosen voltage to the target device. The black plastic enclosure is pocket-sized and needs no software configuration — connect the cables and the link is live.

Passive Operation Over 100 Metres

No fan or external adapter means silent running and zero added power draw beyond the PoE source. The splitter carries both signals up to 100 metres (325 feet) over standard category 5 or better cable. It suits installations that need reliable gigabit throughput without active cooling or a nearby outlet.

Highlights

  • IEEE 802.3af compliant for reliable network power delivery
  • Gigabit ports support up to 1000 Mbps data speeds
  • Selectable 5/9/12V DC output fits varied devices
  • Plug-and-play design requires no configuration
  • Extends power and data up to 100 meters

Specifications

BrandTP-Link
ModelTL-POE10R
TypePoE Splitter
ColorBlack
SpecificationsInterface:
2 x 10/100/1000Mbps RJ45 Port
AUTO Negotiation/AUTO MDI/MDIX
1 x POWER OUTPUT PORT
Network Media
10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
EIA/TIA-568 100O STP (Max 100m)
100BASE-TX: UTP category 5, 5e cable (Max 100m)
EIA/TIA-568 100O STP (Max 100m)
1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)
Power Supply: 12VDC 1A, 9VDC 1A, 5VDC 2A
Basic Function:
Compatible With IEEE 802.3af Compliant PSEs
Delivers Power Up To 100 Meters
Optional 12VDC, 9VDC or 5VDC Power Output
LED Indicator: PWR
Dimensions: 3.2" x 2.0" x 0.9"
Certification: FCC, CE, RoHS
System Requiremen
FeaturesIEEE 802.3af compliant
Delivers power up to 100 meters
Gigabit speed support
Optional 12V DC 9V DC or 5V DC power supply
Plug-and-Play, requires no configuration
Shipping weight0.24 kg
Package size201 × 157 × 66 mm

Questions about this item

What does the IEEE 802.3af standard limit the power delivery distance to on this splitter?

The IEEE 802.3af compliant design delivers power up to 100 meters (328 feet) over a single Ethernet cable.

What cable categories and physical ports are required to connect this splitter?

It uses two Gigabit RJ45 ports and supports UTP category 3, 4, 5 or EIA/TIA-568 100O STP cables up to 100 meters.

How do I set the correct output voltage for my device during installation?

Select 5V, 9V or 12V DC via the output switch before powering on; the unit is plug-and-play with no software configuration needed.
