Small white rectangular box with SC and RJ45 ports

TP-Link

TP-Link MC110CS Fast Ethernet Media Converter 10/100 Mbps 20km SC RJ45

SKU CH-94YY-9XPDW

Converts 10/100 Mbps RJ45 to single-mode SC fiber up to 20 km with Auto MDI/MDIX and link fault passthrough

  • StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3x
  • Fiber CableSingle-mode Fiber
  • Ports1 x 100M SC port 1 x 100M RJ45 port (Auto MDI/MDIX)
  • Max DistanceUp to 20km
  • Transfer Rate10/100 Mbps
  • LEDsPWR, FDX/Col, Link/Act, SPD
  • Extends network reach up to 20 km over single-mode fiber
  • Auto MDI/MDIX RJ45 port removes crossover cable hassle
  • Link Fault Passthrough detects failures fast to limit data loss
  • IEEE 802.3x flow control keeps traffic smooth at 10/100 Mbps
  • Compact 3.7 x 2.9 x 1.1 in chassis fits tight spaces

Product Role

The TP-Link MC110CS is a Fast Ethernet media converter that links a 10/100 Mbps copper segment to a single-mode SC fiber run. It suits installers who need to bridge a building-to-building gap or extend a legacy 100 Mbps network beyond the reach of twisted-pair cabling.

Sustained Operation

The unit runs from an external power adapter and is rated for continuous use between 0 °C and 40 °C with humidity up to 90 % non-condensing. Link Fault Passthrough and Far End Fault signalling detect fibre breaks quickly, reducing the time a segment stays down during a cable fault.

Deciding Specification

The converter supports single-mode fibre up to 20 km, so it is the right part only when the fibre path is single-mode and the required distance fits within that limit. It will not operate on multi-mode fibre or exceed the 20 km reach.

Highlights

  • Extends network reach up to 20 km over single-mode fiber
  • Auto MDI/MDIX RJ45 port removes crossover cable hassle
  • Link Fault Passthrough detects failures fast to limit data loss
  • IEEE 802.3x flow control keeps traffic smooth at 10/100 Mbps
  • Compact 3.7 x 2.9 x 1.1 in chassis fits tight spaces

Specifications

BrandTP-Link
ModelMC110CS
StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3x
Fiber CableSingle-mode Fiber
Ports1 x 100M SC port
1 x 100M RJ45 port (Auto MDI/MDIX)
Max DistanceUp to 20km
Transfer Rate10/100 Mbps
LEDsPWR, FDX/Col, Link/Act, SPD
Power AdapterExternal Power Adapter
Temperature0° ~ 40° C
Humidity10%~90% non-condensing
FeatureBasic Function:
Half/Full-Duplex transfer mode for FX port
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Extends fiber distance up to 20km
Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely
Auto negotiation of 10/100Mbps and auto MID/MID-X for TX port
Provide switch configuration of Half-Duplex / Full-Duplex transfer mode for FX port
Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely
Easy-to-view LED indicators provide status to monitor network activity easily.
Dimensions3.7" x 2.9" x 1.1"

Questions about this item

How much power does the TP-Link MC110CS draw when running continuously?

The unit ships with an external switching power adapter and operates within a 0°C to 40°C temperature range, so typical draw is low enough for passive cooling in a ventilated cabinet.

What cabling and patch panels must I already have to use the SC and RJ45 ports?

You need single-mode fibre terminated with SC connectors for the 100M FX port and standard Cat5 or better copper patch leads for the 10/100M RJ45 port, which supports Auto MDI/MDIX.

Will this converter link reliably to a legacy 10 Mbps half-duplex switch on the copper side?

Yes, the RJ45 port complies with IEEE 802.3 and 802.3u, auto-negotiates 10 or 100 Mbps, and supports half-duplex flow control via backpressure for older equipment.
