White square mesh router with rounded corners and three gigabit ports

TP-Link

TP-Link HX510 1-pack AX3000 mesh Wi-Fi system

SKU CH-VQJ1-R7RTM MPN HX510

A single mesh router delivers Wi-Fi 6 speeds up to 3000 Mbps with three Gigabit ports and WPA3 security

  • ColorWhite
  • TypeMesh Router
  • Router & Satellite Counts1-Pack (1 Router)
  • LAN Ports3 x Gigabit Ports *Per Unit 1 Port supports WAN/LAN auto-sen
  • Wi-Fi StandardsWi-Fi 6
  • Wireless Data RatesAX3000 5 GHz: Up to 2402 Mbps 2.4 GHz: Up to 574 Mbps
  • Wi-Fi 6 delivers combined speeds up to 3000 Mbps across dual bands
  • Three Gigabit LAN ports provide wired backhaul or device connections
  • WPA3 encryption and SPI firewall protect every connected device
  • Parental controls let you manage online time and content per profile
  • EasyMesh certification ensures seamless roaming when you add compatible units

Single-unit mesh foundation

The TP-Link HX510 is a standalone Wi-Fi 6 mesh router delivering AX3000 dual-band speeds up to 3000 Mbps. It creates a unified network that can be expanded with additional EasyMesh units for whole-home coverage. Three Gigabit LAN ports provide wired connectivity for nearby devices. Setup and remote management are handled through the Aginet app and supported cloud protocols.

Suited for expandable single-point starts

This 1-pack suits households that want to begin a mesh system with one router and add satellites later. It fits users who value WPA3 security, parental controls and standard EasyMesh compatibility. Buyers needing immediate multi-room coverage from a single purchase should look at multi-pack mesh kits. Homes requiring more than three wired Ethernet ports per unit will need a switch or a router with additional ports.

AX3000 dual-band throughput

The decisive specification is the AX3000 rating split into 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz. This throughput ceiling determines whether the unit can handle your peak wireless traffic before you invest in extra nodes.

Highlights

  • Wi-Fi 6 delivers combined speeds up to 3000 Mbps across dual bands
  • Three Gigabit LAN ports provide wired backhaul or device connections
  • WPA3 encryption and SPI firewall protect every connected device
  • Parental controls let you manage online time and content per profile
  • EasyMesh certification ensures seamless roaming when you add compatible units

Specifications

BrandTP-Link
ModelHX510(1-pack)
ColorWhite
TypeMesh Router
Router & Satellite Counts1-Pack (1 Router)
LAN Ports3 x Gigabit Ports
*Per Unit
1 Port supports WAN/LAN auto-sensing
Wi-Fi StandardsWi-Fi 6
Wireless Data RatesAX3000
5 GHz: Up to 2402 Mbps
2.4 GHz: Up to 574 Mbps
Frequency Band2.4 GHz / 5 GHz
CertificationsCE, FCC, Wi-Fi CERTIFIED 6, Wi-Fi CERTIFIED EasyMesh
SecurityWPA-PSK/WPA2-PSK/WPA3 Personal encryptions
Parental ControlsYes
Firewall TypeSPI Firewall
ButtonReset Button
WPS Button
OS CompatibilityAndroid 4.4 or later
iOS 9.0 or later
Power Supply12 V = 1.5 A
Dimension4.7" x 4.7" x 3.8"
Operating Temperature0°C - 40°C (32°F - 104°F)
Operating Humidity10%-90% non-condensing
Storage Temperature-40°C - 60°C (-40°F - 140°F)
Storage Humidity5%-90% non-condensing
Package ContentHX510 (1-pack):
1 HX510 Unit
1 RJ45 Ethernet Cable
1 Power Adapter
1 Quick Installation Guide

Questions about this item

How do I install the HX510 and which port should I use for the modem?

Connect the modem to the WAN/LAN auto-sensing port, power the unit with the 12 V 1.5 A adapter, then follow the Aginet app steps to create the network.

What maintenance or replacement will the HX510 need over time?

No user-serviceable parts exist; keep firmware current via the app and ensure the operating temperature stays within 0°C to 40°C for reliable operation.

What limit appears first on the HX510 during sustained heavy traffic?

The three Gigabit LAN ports cap wired throughput at 1 Gbps each, so aggregated wired demand will hit that ceiling before the AX3000 wireless rates.
