White square ceiling-mounted access point with smooth flat surface and recessed indicator lights

TP-Link

TP-Link EAP783 BE22000 Tri-Band Wi-Fi 7 Access Point

SKU CH-RZN1-0NMRT MPN EAP783

Ceiling-mount tri-band Wi-Fi 7 access point delivering up to 22000 Mbps combined throughput with two 10G Ethernet ports and PoE++ power

  • StandardsIEEE 802.11 a/b/g/n/ac/ax/be
  • Wireless Data Rates• 6 GHz: Up to 11520 Mbps • 5 GHz: Up to 8640 Mbps • 2.4 GHz
  • Security• PPSK • VLAN • Access Control • Rogue AP Detection • Captiv
  • AntennaInternal Omni • 2.4 GHz: 4× 4 dBi • 5 GHz: 4× 5.5 dBi • 6 GH
  • Transmitted Power• FCC: <28 dBm (2.4 GHz) <28 dBm (5G band 1&band 4) <24 dBm
  • Interface2× 10G Ethernet Ports
  • Tri-band Wi-Fi 7 delivers up to 22000 Mbps combined throughput
  • Two 10G Ethernet ports provide high-speed wired backhaul for demanding networks
  • PoE++ power enables flexible ceiling mounting without a separate power adapter
  • Centralised Omada SDN cloud management simplifies multi-site network administration
  • Enterprise security with WPA3, captive portal and rogue AP detection protects every connection

Tri-band Wi-Fi 7 access point

The TP-Link EAP783 is a ceiling-mount wireless access point supporting IEEE 802.11be across 2.4 GHz, 5 GHz and 6 GHz bands. It delivers aggregate data rates of up to 22000 Mbps and connects to the wired backbone through two 10G Ethernet ports. Power is supplied via 802.3bt PoE++ or a 12 V DC source. The unit includes mounting hardware for ceiling or wall installation.

High-density environments needing 6 GHz spectrum

Designed for offices, campuses and venues that require high client capacity on the new 6 GHz band with Multi-Link Operation and 4096-QAM. It supports up to 24 SSIDs, captive portal authentication and rogue AP detection for secure guest access. Not suited for deployments without PoE++ infrastructure or a separate 12 V DC supply, since no power adapter is included. Also not intended for outdoor use.

Two 10G Ethernet ports

The dual 10G ports provide the backhaul capacity needed to sustain tri-band Wi-Fi 7 throughput without a wired bottleneck. This is the specification that determines whether the access point can feed the wireless radios at full speed.

Highlights

  • Tri-band Wi-Fi 7 delivers up to 22000 Mbps combined throughput
  • Two 10G Ethernet ports provide high-speed wired backhaul for demanding networks
  • PoE++ power enables flexible ceiling mounting without a separate power adapter
  • Centralised Omada SDN cloud management simplifies multi-site network administration
  • Enterprise security with WPA3, captive portal and rogue AP detection protects every connection

Specifications

BrandTP-Link
ModelEAP783
StandardsIEEE 802.11 a/b/g/n/ac/ax/be
Wireless Data Rates• 6 GHz: Up to 11520 Mbps
• 5 GHz: Up to 8640 Mbps
• 2.4 GHz: Up to 1376 Mbps
Security• PPSK
• VLAN
• Access Control
• Rogue AP Detection
• Captive Portal Authentication?
• Maximum number of MAC Filter: 4,000
• Wireless Isolation between Clients
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, OWE
AntennaInternal Omni
• 2.4 GHz: 4× 4 dBi
• 5 GHz: 4× 5.5 dBi
• 6 GHz: 4× 5 dBi
Transmitted Power• FCC: <28 dBm (2.4 GHz)
<28 dBm (5G band 1&band 4)
<24 dBm (5G band 2&band 3)
<28 dBm (6 GHz)
Interface2× 10G Ethernet Ports
ButtonsReset
Power Supply• 802.3bt PoE++
• 12V DC
Note:Power adapter is not included.
Temperature• Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
Humidity• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing
Dimensions11.0 x 11.0 x 1.8 in (280 x 280 x 46.5 mm)
WeightNet Weight:1384.6g
Package Contents• EAP783
• Installation Guide
• Ceiling/Wall Mounting Kits
Shipping weight2.36 kg
Package size349 × 324 × 95 mm

Questions about this item

Do I need a PoE++ switch or injector to power this AP without the DC adapter?

Yes, the unit accepts 802.3bt PoE++ or 12 V DC; the DC adapter is not included, so a PoE++ source is required unless you supply your own 12 V source.

Will my existing Gigabit switches bottleneck the two 10G Ethernet ports on this AP?

The AP provides two 10G ports; connecting them to Gigabit gear will limit throughput to 1 Gbps per link, but the AP will still operate normally.

How can I confirm the 6 GHz radio is delivering the 11520 Mbps rate after installation?

Check the Omada controller dashboard or client device connection details for a 6 GHz link showing the expected PHY rate and low latency.
