White square ceiling-mount access point with black vents

TP-Link

TP-Link EAP620 HD Wi-Fi 6 AX1800 Wireless Access Point

SKU CH-K71F-H0YB1 MPN EAP620 HD

Dual-band Wi-Fi 6 access point delivers up to 1800 Mbps with OFDMA and MU-MIMO for high-density environments

  • TypeAccessories
  • ColorBlack
  • Wi-Fi 6 speeds up to 1800 Mbps with 1024-QAM and Long OFDM Symbol
  • 4× capacity increase over Wi-Fi 5 using OFDMA and MU-MIMO for high-density deployments
  • Centralised management via Omada SDN with hardware controller, software controller or standalone options
  • Remote cloud access and Omada app for single-interface control from anywhere
  • Dual-band throughput of 1201 Mbps on 5 GHz and 574 Mbps on 2.4 GHz with 4 spatial streams

High-Density Wi-Fi 6 Access Point

The TP-Link EAP620 HD is a wireless access point built for high-density environments such as offices, schools and hospitality venues. It delivers dual-band Wi-Fi 6 connectivity with OFDMA and MU-MIMO to handle many simultaneous client devices. The unit integrates with the Omada SDN platform for centralised management via hardware controller, software controller or cloud access. It is powered by PoE+ for simplified installation.

Upgrade From Wi-Fi 5 In Crowded Spaces

This access point replaces older Wi-Fi 5 (802.11ac) deployments where capacity, not raw speed, is the bottleneck. The jump is worth it when dozens of users share the same airtime and legacy APs cannot schedule traffic efficiently. OFDMA and uplink/downlink MU-MIMO increase network capacity by up to four times versus Wi-Fi 5 in dense scenarios. Standalone operation is also supported for sites without an SDN controller.

Dual-Band Throughput With 4 Spatial Streams

The radio provides 1201 Mbps on the 5 GHz band and 574 Mbps on the 2.4 GHz band, combining for a nominal 1775 Mbps link rate. Four spatial streams and 1024-QAM modulation raise multi-user throughput for concurrent video, voice and data loads. Capacity scales with client count until airtime contention or backhaul limits become the constraint. Sites needing higher aggregate bandwidth or more spatial streams will require additional access points.

Highlights

  • Wi-Fi 6 speeds up to 1800 Mbps with 1024-QAM and Long OFDM Symbol
  • 4× capacity increase over Wi-Fi 5 using OFDMA and MU-MIMO for high-density deployments
  • Centralised management via Omada SDN with hardware controller, software controller or standalone options
  • Remote cloud access and Omada app for single-interface control from anywhere
  • Dual-band throughput of 1201 Mbps on 5 GHz and 574 Mbps on 2.4 GHz with 4 spatial streams

Specifications

TypeAccessories
ColorBlack
Shipping weight1.18 kg
Package size305 × 305 × 83 mm

Questions about this item

Does the EAP620 HD need a PoE+ injector or switch to power it?

Yes, the unit is PoE+ powered so it requires a compatible injector or switch that can supply the higher power class.

How do I adopt the EAP620 HD into the Omada SDN controller for the first time?

Power the AP, ensure it can reach the controller on the network, then use the Omada app or web UI to discover and adopt the device; the step often missed is confirming the controller URL is reachable from the AP VLAN.

Will the radios on the EAP620 HD need firmware updates after installation?

Yes, TP-Link releases firmware for the Omada platform that updates radio drivers and security patches; schedule updates through the controller during maintenance windows.
