Gray cast iron four-bolt flange bearing with ball insert

Timken

Timken Flange Bearing 4-Bolt Ball 1-7/16" Bore SCJ

SKU CH-F241-5N7GJ

Four-bolt flange bearing with 1-7/16 inch bore, cast iron housing and set-screw locking handles 6,400 lb dynamic load from -65 to 200 °F

  • Four-bolt flange design simplifies mounting on flat surfaces
  • 1-7/16 inch bore fits standard shaft diameters
  • 52100 chrome steel insert resists wear under heavy loads
  • Dynamic capacity 6,400 lb handles demanding radial forces
  • Operating range -65 to 200 degrees F suits harsh environments

4-Bolt Flange Bearing for 1-7/16" Shafts

This Timken SCJ series unit mounts a 52100 chrome-steel ball insert inside a cast-iron housing. The four-bolt pattern on a 3 5/8 inch centre spacing suits industrial machinery, conveyor lines and agricultural equipment that run on standard imperial shafts.

Cast-iron housing with set-screw locking

The grey cast-iron body measures 1 1/2 inch overall height and 4 5/8 inch square across the flange. A 1/2 inch bolt size secures the unit while the set-screw collar locks the inner ring to the shaft without additional adapters or special tools.

Lubrication and temperature limits

The bearing ships packed with Mobil Polyrex EM grease, an NLGI #2 equivalent, and operates from -65 °F to 200 °F. Dynamic capacity is 6,400 lb and static capacity is 3,400 lb, so applications exceeding those loads or requiring continuous operation beyond the temperature range need a different bearing solution.

Highlights

  • Four-bolt flange design simplifies mounting on flat surfaces
  • 1-7/16 inch bore fits standard shaft diameters
  • 52100 chrome steel insert resists wear under heavy loads
  • Dynamic capacity 6,400 lb handles demanding radial forces
  • Operating range -65 to 200 degrees F suits harsh environments

Specifications

BrandTimken

Questions about this item

What bolt circle does the 4-bolt flange use?

The mounting holes are spaced 3 5/8 in centre-to-centre and accept 1/2 in bolts.

What are the overall footprint dimensions of the cast-iron housing?

The housing measures 4 5/8 in wide by 4 5/8 in long with a 1 1/2 in overall height.

How is the 1-7/16 in bore secured to the shaft?

A set-screw locking collar clamps the 52100 chrome-steel inner ring to the shaft.
