Silver aluminium mechanical lug with hex socket head and single mounting hole

Thomas & Betts

Thomas & Betts Blackburn ADR60-21 Mechanical Lug 600 kcmil 2 Conductor 1 Hole 1/2 in

SKU CH-6417-VN7Y9

Mechanical lug accepts two aluminum or copper conductors up to 600 kcmil with a single 1/2 in mounting hole

  • TypeElectrical Connectors
  • Accepts copper or aluminium conductors up to 600 kcmil
  • Dual-conductor design terminates two cables in one lug
  • Single 1/2 in mounting hole simplifies panel installation
  • Hex socket head allows fast, secure tightening with standard tools
  • Aluminium body rated for 194 °F and 1 000 V operation

What this lug does

This BLACKBURN mechanical lug connects two conductors up to 600 kcmil each to a single 1/2 in stud. The aluminium body accepts stranded copper or aluminium wire from 2 AWG to 600 kcmil and is rated for 1,000 V at up to 194 Degrees F. A hex-socket head provides the clamping force for both terminations.

Who should use it and who should not

Installers needing a dual-conductor lug with a single mounting hole will find the 1.22 in hole spacing and 2.41 in tongue width fit standard patterns. Projects that require more than two conductors, a different stud size, or a higher temperature rating should look at other connector styles.

Behaviour under sustained load

The aluminium body and hex-socket hardware maintain clamping pressure during continuous operation at the rated 194 Degrees F and 1,000 V. The 0.44 in tongue thickness and 1.81 in tongue length provide stable contact area for both conductors under steady thermal cycling.

Highlights

  • Accepts copper or aluminium conductors up to 600 kcmil
  • Dual-conductor design terminates two cables in one lug
  • Single 1/2 in mounting hole simplifies panel installation
  • Hex socket head allows fast, secure tightening with standard tools
  • Aluminium body rated for 194 °F and 1 000 V operation

Specifications

BrandBLACKBURN
TypeElectrical Connectors

Questions about this item

What conductor sizes and materials does the ADR60-21 lug accept?

The lug is rated for stranded copper from 2 AWG up to 600 kcmil and also accepts aluminium conductors.

Can I use this two-conductor lug with a single 1/2 in stud on existing busbars?

Yes, it has one 0.5 in hole on 1.22 in spacing, a 1.81 in tongue length and 2.41 in width, so it fits standard 1/2 in stud patterns.

How do I verify the connection is correct after torquing the hex-socket screws?

Confirm each conductor is fully seated, the hex-socket screws are tight, and the lug body does not exceed 194 °F under load.
