Small silver box with four rotary knobs and RCA jacks

TENEALAY R41 4-Channel Passive Audio Mixer

SKU CH-CBTE-WM924

A compact passive mixer with four stereo RCA inputs and one stereo RCA output, each channel with independent volume control, requiring no power supply

  • Specification, TENEALAY, , , , Count, 1, RCA, 160 grams, R41, , 52161500,
  • Power SupplyPassive
  • Dimension95 L x 90 W x 40 H millimeters
  • Weight160 grams
  • Connect four stereo sources simultaneously
  • each channel has independent volume control
  • passive design needs no power supply
  • ultra-compact at 95 x 90 x 40 mm
  • doubles as 1-in-4-out splitter when knobs maxed

Stereo four-channel passive mixer

The TENEALAY R41 combines four stereo RCA sources into one stereo RCA output. Each channel has its own volume knob for independent level control. It operates without any power supply, making it a simple plug-and-play solution for desktop or office use.

Passive mixing and signal attenuation

Because the unit has no internal amplifier, the output signal is attenuated. High-impedance loads such as powered speakers or headphone amplifiers lose little level, while low-impedance loads such as passive headphones lose more. The mixer can also function as a one-input to four-output splitter when all knobs are turned fully clockwise.

Compact aluminium enclosure with RCA connectivity

The chassis measures 95 by 90 by 40 millimetres and weighs 160 grams, so it fits easily on a crowded desk. Four stereo RCA input pairs and one stereo RCA output pair are mounted on the panel for quick cable access. No external power brick or batteries are required, keeping the setup minimal and portable.

Highlights

  • Connect four stereo sources simultaneously
  • each channel has independent volume control
  • passive design needs no power supply
  • ultra-compact at 95 x 90 x 40 mm
  • doubles as 1-in-4-out splitter when knobs maxed

Specifications

BrandTENEALAY
Part NumberR41
Specification, TENEALAY, , , , Count, 1, RCA, 160 grams, R41, , 52161500, TENEALAY, R41, , 95 L x 90 W x 40 H millimeters, 1, Passive, false, false, 4, 0.222 kilograms, 30., , RCA, , , , , , 5.4102 L x 11.2014 W x 11.303 H centimeters, 2023-01-05T08:05:22.176Z, ,
Power SupplyPassive
Dimension95 L x 90 W x 40 H millimeters
Weight160 grams

Questions about this item

How do I decide between the four stereo RCA inputs and the single stereo RCA output on the R41?

The mixer provides four stereo RCA inputs each with an independent volume knob and one stereo RCA output. Connect up to four sources simultaneously and blend them, or turn all knobs fully clockwise to use it as a one‑in‑four‑out splitter.

What does the passive design mean for signal level when I connect the R41 to my amplifier?

Because the R41 has no internal amplifier, the output is attenuated. High‑impedance loads such as powered speakers lose little level, while low‑impedance loads like headphones lose more.

How does the passive RCA interface affect the maximum cable length I can run?

The unbalanced RCA connections on the R41 are best kept short — typically under a few metres — to avoid noise pickup and high‑frequency loss, especially when driving low‑impedance destinations.
