Telemecanique Sensors
Telemecanique Sensors XS8C4A4MPN12 40mm Inductive Rectangular Proximity Sensor 24-240V AC/DC
Inductive rectangular proximity sensor detects metal at 40 mm, runs on 24-240 V AC/DC, and withstands harsh environments with IP65, IP67 and IP69K ratings
- Reliable detection up to 40 mm sensing range
- Flexible 24 to 240 V AC/DC supply voltage
- Rugged IP65 IP67 IP69K protection rating
- Wide -13 to 158 °F operating temperature
- Simple two-wire screw-clamp terminal connection
Industrial Proximity Sensor 40mm Range
The Telemecanique Sensors XS8C4A4MPN12 is an inductive rectangular proximity sensor built for factory automation and machinery monitoring. It detects metal targets up to 40 mm away without physical contact. The unit operates on a wide 24 to 240V AC/DC supply, making it suitable for varied industrial power networks.
Screw Terminal Wiring and IP69K Sealing
A screw clamp terminal block provides secure wire connections that resist vibration in heavy equipment. The plastic housing carries IP65, IP67 and IP69K ratings, so the sensor withstands water jets, temporary immersion and high-pressure wash-downs common in food or outdoor installations. An unshielded design allows the maximum 40 mm sensing distance on a 117 mm long body.
Verify Voltage, Output Logic and Mounting Clearance
Confirm that your control system accepts a two-wire NO/NC output with a 300 mA AC or 200 mA DC load limit before wiring. The operating temperature range spans -13 to 158 degrees F, so check that the mounting location stays within these limits. Ensure the rectangular footprint and 117 mm length fit the available bracket space on your machine frame.
Highlights
- Reliable detection up to 40 mm sensing range
- Flexible 24 to 240 V AC/DC supply voltage
- Rugged IP65 IP67 IP69K protection rating
- Wide -13 to 158 °F operating temperature
- Simple two-wire screw-clamp terminal connection
Specifications
| Brand | TELEMECANIQUE SENSORS |
|---|
Questions about this item
Does the screw-clamp terminal need periodic re-tightening on the XS8C4A4MPN12?
The screw-clamp terminal is designed for a secure initial connection; no scheduled re-tightening interval is specified by Telemecanique Sensors.
What limits continuous operation of the 200 Hz switching frequency?
The 300 mA AC / 200 mA DC maximum load current is the first limit reached under sustained 200 Hz switching.
How much heat does the plastic case dissipate when powered at 240 V all day?
The sensor operates from -13 °F to 158 °F ambient; self-heating stays within that range at the rated 300/200 mA load.
