Telemecanique Sensors XS7C4A1MPG13 Inductive Proximity Sensor 15 mm 24-240 V AC/DC PG13 IP65/67/69K
Rectangular inductive proximity sensor detects metal at 15 mm on 24-240 V AC/DC with PG13 screw terminals, IP65/67/69K sealing and -13 to 158 °F operation
- 15 mm sensing range for reliable detection
- 24-240 V AC/DC supply fits many control circuits
- IP65, IP67 and IP69K ratings withstand harsh wash-down
- 300 Hz switching frequency supports fast automation cycles
- 13 °F to 158 °F operating range suits extreme environments
Telemecanique Inductive Proximity Sensor 15 mm
This inductive rectangular proximity sensor detects metal objects at a maximum distance of 15 mm. It operates on a wide 24 to 240 V AC/DC supply with a 2-wire output circuit. The sensor offers selectable NO or NC output modes and a 300 Hz switching frequency. Rated IP65, IP67 and IP69K, the PBT housing withstands harsh washdown and industrial environments.
PG13 Screw Terminal Connection Simplifies Wiring
The PG13 screw terminal block allows direct cable termination without specialised connectors. Ensure the cable gland matches the PG13 thread to maintain the IP69K seal. A common issue is exceeding the 200 mA or 300 mA maximum load current, which can damage the output stage. Verify the load current stays within limits and that the operating temperature remains between -13 and 158 degrees F.
Check Supply Voltage and Mounting Clearance Before
Confirm your control system provides 24 to 240 V AC/DC compatible with the sensor's 2-wire interface. The shielded design permits flush mounting in metal, but the 40 mm body length requires adequate installation depth. Ensure the target material and speed suit the 300 Hz operating frequency. Buyers needing non-metallic detection or longer sensing ranges should consider alternative technologies.
Highlights
- 15 mm sensing range for reliable detection
- 24-240 V AC/DC supply fits many control circuits
- IP65, IP67 and IP69K ratings withstand harsh wash-down
- 300 Hz switching frequency supports fast automation cycles
- 13 °F to 158 °F operating range suits extreme environments
Specifications
| Brand | TELEMECANIQUE SENSORS |
|---|
Questions about this item
How can I verify the XS7C4A1MPG13 is detecting correctly after installation?
Apply a metal target within the 15 mm sensing range and confirm the output switches at the 300 Hz operating frequency.
What comes with the sensor and what must I supply separately?
The sensor body with PG13 screw terminals is included; mounting hardware and a 24 to 240 V AC/DC power source are not.
Which output configuration should I choose for a simple on/off control circuit?
The NO/NC selectable output mode lets you wire either normally-open or normally-closed logic with the same 2-wire connection.
