Cylindrical nickel-plated brass inductive proximity sensor with M12 connector

Telemecanique Sensors

Telemecanique Sensors XS630B1PAM12 Inductive Proximity Sensor 30 mm

SKU CH-8YMT-HBRW6

A 30 mm shielded inductive proximity sensor detects metal up to 15 mm away, runs on 12 to 48 V DC with a 3-wire PNP output, and withstands harsh environments with IP67 and IP69K ratings

  • TypeIndustrial Electrical Controls & Automation
  • Detects metal targets up to 15 mm away
  • Operates on 12 to 48 V DC supply voltage
  • IP67 and IP69K ratings resist water and high-pressure washdown
  • 500 Hz switching frequency suits fast automation cycles
  • Nickel-plated brass housing withstands -13 to 158 °F environments

Cylindrical Inductive Sensor 30 mm

The Telemecanique Sensors XS630B1PAM12 is a cylindrical inductive proximity sensor built for industrial automation. Its 30 mm diameter housing fits standard mounting points on machinery and conveyors. The shielded design allows flush installation in metal without affecting the sensing field. It targets presence detection of metallic parts in harsh environments.

Thermals Noise and Power Draw

The sensor operates on a 12 to 48V DC supply with a maximum current load of 200 mA. A 500 Hz switching frequency supports fast cycling on production lines. IP67 and IP69K ratings confirm protection against dust ingress and high-pressure washdown. The nickel-plated brass case withstands temperatures from -13 to 158 degrees F.

Build Integration Requirements

A 4-pin M12 connector provides the electrical interface for quick wiring in control cabinets. The 3-wire PNP normally open output connects directly to PLC inputs. With a 15 mm maximum detecting distance the unit suits close-range part verification. The 74 mm overall length determines the depth needed behind the mounting face.

Highlights

  • Detects metal targets up to 15 mm away
  • Operates on 12 to 48 V DC supply voltage
  • IP67 and IP69K ratings resist water and high-pressure washdown
  • 500 Hz switching frequency suits fast automation cycles
  • Nickel-plated brass housing withstands -13 to 158 °F environments

Specifications

BrandTELEMECANIQUE SENSORS
TypeIndustrial Electrical Controls & Automation

Questions about this item

How do I mount the 30 mm cylindrical sensor and wire the 4-pin M12 connector without reversing the PNP output?

Mount the nickel-plated brass barrel with the shielded face toward the target, then connect the 4-pin M12 plug so that the load sits between the output wire and 0 V; reversing the load to the positive rail will keep the output high constantly.

What part of this IP67/IP69K sensor will need replacement first in a wash-down environment?

The sensing face and M12 connector seals are rated for high-pressure wash-down at 158 °F; inspect the connector O-ring and cable jacket annually and replace the whole unit if the sensing face shows pitting or the LEDs fail.

At what point does the 500 Hz switching limit affect detection of fast-moving parts?

The 500 Hz operating frequency allows a new output state every 2 ms; targets passing the 15 mm sensing zone faster than that dwell time will be missed, so line speed must stay below the distance-per-2 ms threshold.
