Telemecanique Sensors XS630B1MAU20 Inductive Proximity Sensor 30 mm
Cylindrical inductive sensor detects metal at 15 mm with 24–240 V AC/DC supply and IP67/IP69K sealing
- 15 mm detection range for reliable presence sensing
- 24–240 V AC/DC supply fits wide control voltages
- IP67 and IP69K ratings withstand wash-down and immersion
- Nickel-plated brass housing resists corrosion in harsh environments
- 13 °F to 158 °F operating range suits extreme temperatures
Industrial Detection Solution
The Telemecanique Sensors XS630B1MAU20 is a 30 mm cylindrical inductive proximity sensor built for machine-shop and automation tasks. It suits engineers who need reliable non-contact metal detection at a 15 mm range in harsh environments. The 24 to 240V AC/DC supply range simplifies integration into existing control panels. Buyers needing longer sensing distances or non-metallic target detection should look elsewhere.
Rugged Thermal And Electrical Performance
The nickel-plated brass housing carries IP67 and IP69K ratings plus NEMA 4X protection against water, dust and high-pressure wash-down. Operating temperature spans -13 to 158 degrees F without derating. The two-wire output circuit draws minimal current at 25 Hz AC or 500 Hz DC switching frequencies. No external cooling or special wiring practices are required for normal operation.
Ready-To-Mount Connection Kit
A 3-pin 1/2-20 UNF male connector is factory-fitted on the 73 mm body for quick plug-in installation. The normally-open output mode works directly with standard PLC input modules. Shielded construction allows flush mounting in metal brackets without sensing interference. No separate mounting hardware, configuration software or programming cables are supplied.
Highlights
- 15 mm detection range for reliable presence sensing
- 24–240 V AC/DC supply fits wide control voltages
- IP67 and IP69K ratings withstand wash-down and immersion
- Nickel-plated brass housing resists corrosion in harsh environments
- 13 °F to 158 °F operating range suits extreme temperatures
Specifications
| Brand | TELEMECANIQUE SENSORS |
|---|
Questions about this item
How do I mount and wire the 30 mm cylindrical sensor with the 1/2-20 UNF 3-pin male connector?
Thread the nickel-plated brass body into a 30 mm cut-out, tighten the lock-nuts to the recommended torque, then plug the 3-pin 1/2-20 UNF connector until it clicks; the common mistake is cross-threading the fine UNF threads or leaving the connector loose, which breaks the IP67/IP69K seal.
What maintenance or replacement will the XS630B1MAU20 need over time?
The solid-state output has no moving parts to wear, so only periodic cleaning of the sensing face to remove metal chips or coolant residue is required; if the housing is cracked or the connector pins are bent, replace the entire unit.
At what point does the 25 Hz AC / 500 Hz DC switching frequency limit sustained operation?
The sensor cannot reliably detect targets moving faster than 25 cycles per second on AC or 500 cycles per second on DC; beyond those rates the output will miss pulses, which is the first limit reached under continuous high-speed use.
