Telemecanique Sensors XCSLE 2525513 Safety Interlock Switch Plastic 1NO/1NC
Plastic safety interlock switch with solenoid locking, 1NO/1NC contacts, IP66/IP67 rating, operating from -13 to 140 °F
- Plastic body resists corrosion in harsh environments
- Solenoid locking at 24 V AC/DC secures guard doors
- 1NO/1NC contacts suit standard safety circuits
- IP66 and IP67 ratings withstand wash-down and immersion
- Operating range from -13 °F to 140 °F covers extreme conditions
Safety interlock switch for machine guarding
The Telemecanique Sensors XCSLE 2525513 is a plastic safety interlock switch designed for machine guarding applications. It features a solenoid locking mechanism that operates on 24 V AC/DC and provides a 1NO/1NC contact configuration. The switch body is made of plastic with a polyamide head and carries IP66 and IP67 ratings for dust and water ingress protection. It operates across a temperature range of -13 Degrees to 140 Degrees F.
Replaces mechanical interlocks without solenoid
This switch upgrades basic mechanical interlocks by adding solenoid locking with power, allowing the guard to remain locked until a control signal releases it. The jump is worth it when a process requires the guard to stay closed until hazardous motion has stopped or a specific sequence is completed. It connects via a 1/2 in NPT conduit entry and carries an AC contact rating of 0.75 A @ 240 V and a DC contact rating of 0.55 A @ 24 V. The double-insulated construction adds a layer of protection against electrical shock.
Limited to low-power control circuits
The practical limit of this switch is its contact ratings, which restrict it to low-power control circuits rather than direct motor switching. The 0.75 A AC and 0.55 A DC ratings mean it must drive a contactor or relay for higher loads. The 1/2 in NPT conduit connection dictates the wiring method, and the fixed 8.07 in height, 1.71 in width, and 2.01 in depth determine the mounting footprint. It is not suited for applications requiring higher current switching or different conduit sizes.
Highlights
- Plastic body resists corrosion in harsh environments
- Solenoid locking at 24 V AC/DC secures guard doors
- 1NO/1NC contacts suit standard safety circuits
- IP66 and IP67 ratings withstand wash-down and immersion
- Operating range from -13 °F to 140 °F covers extreme conditions
Specifications
| Brand | TELEMECANIQUE SENSORS |
|---|
Questions about this item
What conduit size does the 1/2 in NPT opening on the XCSLE 2525513 accept?
The switch uses a 1/2 in NPT conduit connection for cable entry.
How is the solenoid-powered locking mechanism on the XCSLE 2525513 wired for 24 V AC/DC supply?
Connect the supply to the solenoid terminals; the lock engages when the 24 V AC/DC signal is present.
When should the plastic body and polyamide head of the XCSLE 2525513 be inspected for replacement?
Inspect regularly for cracks or UV damage; replace if the IP66/IP67 seal is compromised or the operating temperature exceeds 140 °F.
