Telemecanique Sensors
Telemecanique Sensors XCSDMP5012 1NC/2NO Safety Interlock
Magnetically actuated safety interlock with 1NC/2NO contacts, IP66/IP67 rating, and pre-cabled 6.56 ft connection for machine guarding applications
- Magnetically coded actuation prevents tampering and defeat
- 1NC/2NO contacts give safe monitoring and control
- IP66/IP67 rating withstands wash-down and harsh environments
- Pre-cabled 6.56 ft connection speeds up installation
- LED status indicator simplifies diagnostics and alignment
Magnetically Actuated Safety Interlock
The Telemecanique Sensors XCSDMP5012 is a magnetically actuated safety interlock switch designed for machine guarding applications. It uses a coded magnetic actuator to monitor guard position without physical contact, reducing mechanical wear. The unit suits OEMs and maintenance teams building safety circuits for automated equipment. Its pre-cabled termination simplifies installation in new or retrofit panels.
LED Indication and IP66/IP67 Sealing
The built-in LED provides local visual status of the switch state, aiding commissioning and troubleshooting without extra test equipment. A 6.56 ft pre-wired cable eliminates separate connector purchases and reduces wiring time. IP66 and IP67 ratings allow the switch to withstand high-pressure washdown and temporary immersion common in food, packaging and pharmaceutical lines. Plastic housing resists corrosion from cleaning chemicals.
1NC/2NO Contact Form for Safety Circuits
The contact arrangement delivers one normally closed and two normally open circuits rated at 0.1 A at 24 V DC, matching standard safety-relay input requirements. This configuration supports redundant monitoring architectures demanded by functional-safety standards. Buyers who need higher switching current or a different contact mix must select an alternative model. Operating temperature spans -13 °F to 185 °F for indoor and covered outdoor use.
Highlights
- Magnetically coded actuation prevents tampering and defeat
- 1NC/2NO contacts give safe monitoring and control
- IP66/IP67 rating withstands wash-down and harsh environments
- Pre-cabled 6.56 ft connection speeds up installation
- LED status indicator simplifies diagnostics and alignment
Specifications
| Brand | TELEMECANIQUE SENSORS |
|---|
Questions about this item
Does the 6.56 ft pre-cabled termination need periodic replacement in a machine-shop environment?
The 6.56 ft cable is factory-fitted; inspect the jacket and connections during routine guarding audits and replace the complete unit if insulation damage or conductor fatigue is found.
At 0.1 A @ 24 V DC, what electrical limit appears first when the guard is cycled continuously?
The 0.1 A DC contact rating is the limiting factor; sustained switching at or above this current will accelerate contact wear before mechanical or thermal limits are reached.
How much heat does the LED indicator add inside an IP66/IP67 enclosure running all day?
The LED draws only a few milliamps at 24 V, so its thermal contribution is negligible compared with the -13 °F to 185 °F operating range of the switch body.
