Telemecanique Sensors XCSDMC5912 1NC/1NO magnetic safety interlock
Magnetically actuated safety interlock with 1NO/1NC contacts, IP66/IP67 rating, pre-cabled 6.56 ft, operating from -13 to 185 °F
- Magnetically coded safety prevents tampering on guard doors
- 1NO/1NC contacts suit safety relay monitoring circuits
- Pre-cabled 6.56 ft length reduces wiring time
- IP66 and IP67 sealing resists wash-down and dust
- 13 to 185 °F range covers cold stores and hot zones
Safety interlock for machine guarding
The Telemecanique Sensors XCSDMC5912 is a magnetically actuated safety interlock switch designed for machine guarding applications. It uses a coded magnetic actuator to monitor guard position without mechanical wear. The 1NC/1NO contact form provides both safety and signalling circuits in a single device. It suits original equipment manufacturers and maintenance teams specifying non-contact safety switching.
Consistent sensing across temperature extremes
The switch operates reliably from -13 degrees to 185 degrees Fahrenheit, maintaining its on sensing distance of .2 inches and off sensing distance of .59 inches throughout that range. DC contact rating is .1 A at 24 V, so the contacts handle low-power control circuits directly without intermediate relays. Pre-cabled termination with 6.56 feet of cable reduces installation time and eliminates connector failure points. IP66 and IP67 ratings confirm protection against powerful water jets and temporary immersion.
Compact plastic housing simplifies mounting
The switch body measures .63 inches wide, 2.01 inches high and .28 inches deep, matching the actuator dimensions for straightforward alignment. Plastic construction resists corrosion and reduces weight on lightweight guards. Integrated LED provides local status indication for faster troubleshooting. Pre-cabled design means no field wiring to terminals, so the device can be replaced without tools in minutes.
Highlights
- Magnetically coded safety prevents tampering on guard doors
- 1NO/1NC contacts suit safety relay monitoring circuits
- Pre-cabled 6.56 ft length reduces wiring time
- IP66 and IP67 sealing resists wash-down and dust
- 13 to 185 °F range covers cold stores and hot zones
Specifications
| Brand | TELEMECANIQUE SENSORS |
|---|
Questions about this item
Does the XCSDMC5912 generate noticeable heat or noise when powered continuously at 24 V DC?
The switch draws only 0.1 A at 24 V DC and has no moving parts, so it produces negligible heat and runs silently during all-day operation.
What separate component must I already have to make the XCSDMC5912 function as a safety interlock?
You need the matching coded magnetic actuator; the interlock only switches when that actuator comes within 0.2 in and releases when it moves beyond 0.59 in.
Will the XCSDMC5912 fit the same 0.63 in mounting footprint as the older plastic-body safety switches I already use?
Yes, both the switch and its actuator share a 0.63 in width, 2.01 in height and 0.28 in depth, so they match the common rectangular footprint used by earlier models.
