Telemecanique Sensors XCSDM5002 Magnetically Actuated Safety Interlock 1NC/2NO IP66/IP67 6.56ft Cable
Magnetically actuated safety interlock with 1NC/2NO contacts, IP66/IP67 rating, and 6.56ft pre-wired cable for industrial machine guarding
- Magnetically actuated safety interlock prevents accidental restarts
- 1NC/2NO contact form with 0.1 A at 24 V DC rating
- IP66 and IP67 sealed for dust and water ingress protection
- 56 ft pre-cabled termination simplifies installation wiring
- Operating range -13 °F to 185 °F suits harsh environments
Magnetically Actuated Safety Interlock
The Telemecanique Sensors XCSDM5002 is a magnetically actuated safety interlock switch designed for industrial machinery guarding. It provides reliable position monitoring for gates and guards in automation environments. The unit suits safety circuits requiring non-contact actuation with a coded magnetic key.
Contact Form 1NO and 0.1 A Rating
This switch operates with a 1NO contact form and a DC contact rating of 0.1 A at 24 V. That single specification determines whether the device matches the control circuit current and voltage requirements. Verify the load before installation to ensure compatibility.
IP66/IP67 Pre-Cabled 6.56 ft Cable
The switch arrives with a pre-cabled 6.56 ft vinyl coated nylon fabric cable sealed to IP66 and IP67 ratings. This eliminates separate connector sourcing and wiring time while resisting dust and water ingress. The fixed cable length sets the maximum routing distance to the controller.
Highlights
- Magnetically actuated safety interlock prevents accidental restarts
- 1NC/2NO contact form with 0.1 A at 24 V DC rating
- IP66 and IP67 sealed for dust and water ingress protection
- 56 ft pre-cabled termination simplifies installation wiring
- Operating range -13 °F to 185 °F suits harsh environments
Specifications
| Brand | TELEMECANIQUE SENSORS |
|---|
Questions about this item
What does the 0.1 A at 24 V DC rating mean for my safety circuit?
The switch can reliably carry up to 0.1 A at 24 V DC, so size your safety relay or controller inputs to stay within that limit.
How do the IP66 and IP67 ratings protect the switch in a wet environment?
IP66 guards against powerful water jets while IP67 allows temporary immersion up to 1 m, so the switch survives wash-down and accidental submersion.
Will the 0.98 in wide body fit on my existing guard mounting holes?
The switch body and actuator each measure 0.98 in wide by 3.46 in high by 0.52 in deep, so verify your hole pattern matches those dimensions.
