Telemecanique Sensors XCKJ10511H7 Limit Switch Roller Lever
Heavy-duty limit switch with roller lever actuator, 1NC/1NO contacts rated 10A at 240V AC/DC, NEMA 1, 2, 4, 12, 13 enclosure
- Reliable AC switching up to 10 A at 240 V
- Durable DC control at 10 A and 240 V
- Versatile 1NC/1NO contact form for flexible wiring
- Compact body fits tight spaces at 4.01 × 1.57 × 2.36 in
- Protected in harsh environments with NEMA 1, 2, 4, 12, 13 ratings
Heavy-duty limit switch for industrial machinery
The Telemecanique Sensors XCKJ10511H7 limit switch uses a roller-lever actuator mounted on the side of a standard body. It provides one normally-open and one normally-closed contact rated at 10A for both 240V AC and 240V DC circuits. NEMA 1, 2, 4, 12 and 13 ratings make it suitable for indoor and outdoor equipment that requires reliable position sensing.
Sealed construction handles dust.
The switch body measures 4.01 in high, 1.57 in wide and 2.36 in deep with no boot seal on the actuator. Its enclosure meets NEMA 12 and 13 requirements for protection against circulating dust, falling dirt and oil or coolant splashing. The rugged housing and side-mounted lever operate without external cooling or lubrication in typical factory environments.
Side-entry actuator suits tight machine frames
The 1.61 in roller lever protrudes from the side, allowing the switch to sit flush against panels or guards where front access is limited. Wiring connects to screw terminals inside the standard body, leaving the top and bottom faces clear for conduit entry. No auxiliary power supply or control module is required, so the switch integrates directly into existing safety or sequencing circuits.
Highlights
- Reliable AC switching up to 10 A at 240 V
- Durable DC control at 10 A and 240 V
- Versatile 1NC/1NO contact form for flexible wiring
- Compact body fits tight spaces at 4.01 × 1.57 × 2.36 in
- Protected in harsh environments with NEMA 1, 2, 4, 12, 13 ratings
Specifications
| Brand | TELEMECANIQUE SENSORS |
|---|
Questions about this item
How do I install the XCKJ10511H7 limit switch and what is the common mistake?
Mount the switch using the standard body dimensions of 4.01 in height, 1.57 in width and 2.36 in depth; the step often missed is aligning the 1.61 in roller lever so it engages the cam perpendicularly to avoid side loading.
What maintenance or replacement will the XCKJ10511H7 need over time?
The roller lever actuator and internal 1NC/1NO contacts are the wear items; inspect the lever for flat spots and the contacts for pitting after heavy cycling, and replace the complete switch if the NEMA 4 seal integrity is compromised.
What limit appears first on the XCKJ10511H7 during sustained operation?
The 10 A at 240 V AC or DC contact rating is the first electrical limit; exceeding this current will cause contact overheating and premature failure before the mechanical lever reaches its endurance limit.
