TeKit NTRAT100011 Ultrasonic Thickness Gauge 1.2-220mm Yellow
Measures material thickness from 1.2 to 220 mm using ultrasonic technology with auto-calibration and stores up to 10 readings
- TypeElectronic
- Equipment TypeDigital Ultrasonic Thickness Meter Tester Gauge Metal Tester
- ColorYellow
- MaterialPlastic
- Working Distance1.2-220mm
- Number of FunctionsDigital Ultrasonic Thickness Meter Tester Gauge Metal Tester
- Measures 1.2-220 mm wall thickness on steel, aluminium, titanium, plastics, ceramics, glass
- Sound velocity measurement with ±1 % accuracy over 20 mm and ±5 % under 20 mm
- Auto calibration and coupling status indication for reliable readings
- Stores and recalls 10 measurements for quick reference
- Palm-size yellow plastic housing for portable on-site use
TeKit NTRAT100011 Ultrasonic Gauge
The TeKit NTRAT100011 is a palm-sized digital ultrasonic thickness gauge designed for measuring material wall thickness from 1.2 to 220mm. It suits engineers, inspectors and hobbyists who need non-destructive testing of metals, plastics, ceramics and glass with parallel surfaces. The yellow plastic housing contains an LCD display and simple controls for field or workshop use.
Measurement range and accuracy limits
The gauge measures thicknesses between 1.2mm and 220mm with selectable sound velocity settings for different materials. Accuracy is +/-1% when measuring known thicknesses over 20mm and +/-5% for thicknesses under 20mm. It stores up to 10 readings for later recall and includes coupling status indication to confirm good probe contact. The device cannot measure materials without parallel top and bottom surfaces.
Power and operating characteristics
The instrument runs on standard batteries housed inside the plastic case for portable operation. Auto-calibration and automatic zero reset simplify setup before each measurement session. The LCD readout provides clear values in normal ambient light without backlight glare. No external power supply or computer connection is required for basic thickness and sound velocity measurement tasks.
Highlights
- Measures 1.2-220 mm wall thickness on steel, aluminium, titanium, plastics, ceramics, glass
- Sound velocity measurement with ±1 % accuracy over 20 mm and ±5 % under 20 mm
- Auto calibration and coupling status indication for reliable readings
- Stores and recalls 10 measurements for quick reference
- Palm-size yellow plastic housing for portable on-site use
Specifications
| Brand | Tekit |
|---|---|
| Model | NTRAT100011 |
| Type | Electronic |
| Equipment Type | Digital Ultrasonic Thickness Meter Tester Gauge Metal Tester |
| Color | Yellow |
| Material | Plastic |
| Working Distance | 1.2-220mm |
| Number of Functions | Digital Ultrasonic Thickness Meter Tester Gauge Metal Tester |
| Features | Digital Ultrasonic Thickness Meter Tester Gauge Metal Tester |
Questions about this item
Will the probe connect to my existing ultrasonic flaw detector that uses a Lemo 00 connector?
The gauge has an integrated probe and is designed as a standalone instrument, so it does not accept external transducers or Lemo connectors.
How do I verify the GM100 is reading correctly after I calibrate it?
Use a reference block of known thickness; the LCD should display that value within the stated accuracy of ±1 % over 20 mm or ±5 % under 20 mm.
Does the NTRAT100011 ship with couplant gel and a calibration block, or must I buy them separately?
The listing describes the gauge only; couplant and a reference block for calibration are not included and must be purchased separately.
