Grey metal floor pedal with rubber base XLR and guitar jacks USB port power input footswitch and harmony controls

TC

TC Helicon VoiceTone H1 Harmony Effect Pedal

SKU CH-N461-FFNM7

Adds up to two natural-sounding harmony voices with eight styles, auto-detecting key from guitar input and chaining with other VoiceTone pedals

  • Two natural harmony voices with eight style choices
  • Guitar input auto-detects song key and scale instantly
  • Rugged die-cast metal chassis with rubberised base stays put
  • Mic Control enables remote on/off with MP-75 microphone
  • 24 V phantom power always on for condenser microphones

Purpose and User

The TC Helicon VoiceTone H1 is a floor pedal that adds up to two harmony voices above or below a lead vocal. It suits singers who want instant harmonies without menu diving, whether performing solo with a guitar or running a dedicated vocal chain. Guitarists benefit from automatic key detection through the instrument input, while other vocalists can set the key manually.

Bundled Extras and Control

A 12 V 0.4 A power supply is included so the unit works straight out of the box. A USB port allows firmware updates and parameter editing from a computer. Remote on/off switching is possible when paired with the optional TC-Helicon MP-75 microphone, letting the singer toggle harmonies without bending down. Chaining multiple VoiceTone Singles expands the effects palette without extra cabling complexity.

Interface Limits

The XLR microphone input accepts levels from -42 dBu to +1 dBu with 24 V phantom power always active, so dynamic and condenser mics are both supported. Guitar input impedance is 1 MΩ and handles -7 dBu to +17 dBu. Balanced outputs present 200 Ω impedance and deliver +1 dBu full scale with greater than 104 dB dynamic range from 20 Hz to 20 kHz. Power draw is 5.6 W.

Highlights

  • Two natural harmony voices with eight style choices
  • Guitar input auto-detects song key and scale instantly
  • Rugged die-cast metal chassis with rubberised base stays put
  • Mic Control enables remote on/off with MP-75 microphone
  • 24 V phantom power always on for condenser microphones

Specifications

No published specifications for this item yet.

Questions about this item

Does the XLR microphone input need any periodic servicing or phantom-power component replacement?

The XLR input provides 24 V phantom power that is always on, and the preamp achieves an EIN of -126 dBu at 150 Ω; no user-serviceable parts are inside the sealed die-cast chassis.

What limits continuous operation — thermal shutdown, DSP headroom or the 5.6 W power budget?

The unit draws 5.6 W from the supplied 12 V 0.4 A adapter, runs with a rubberised base for passive cooling, and specifies a dynamic range above 104 dB with no thermal-limit mention.

How much heat or fan noise appears when the pedal stays on all day?

There is no fan; the metal chassis and rubberised base dissipate the 5.6 W silently, and the balanced outputs hold +0/-0.3 dB from 20 Hz to 20 kHz during extended use.
