Taco Inc
Taco Inc 0012-SF4 Stainless Steel Circulator Thermostat
A stainless-steel circulator pump for potable water systems delivers up to 50 gpm at 1 ft head with a 1/8 hp, 115 V single-phase motor
- TypeLearning Thermostats
- Learn your heating patterns with built-in learning thermostat technology
- Delivers up to 50 gallons per minute at low head pressure
- Maintains 39 gallons per minute at moderate 5-foot head
- Provides 24 gallons per minute at 10-foot head for efficient circulation
- Flanged connections fit four pipe sizes for versatile installation
TACO 0012-SF4 Stainless Circulator
This TACO 0012-SF4 is a stainless steel circulating pump built for potable water systems. It suits residential or light commercial hydronic installations that need reliable fluid movement. The unit operates on 115V AC single-phase power with a 1/8 hp motor. Its learning thermostat capability helps match output to system demand.
Upgrading from older fixed-speed pumps
The pump replaces fixed-speed circulators that run constantly at one rate. The jump is worth it when you want the motor to adapt its operation based on system conditions. At 1 foot of head it delivers 50 gpm, at 5 feet it delivers 39 gpm, and at 10 feet it delivers 24 gpm. Maximum head is 15 feet where flow reaches 0 gpm.
Flanged installation with common pitfalls
Flanged connections simplify mounting to compatible pipework in 3/4, 1, 11/4, or 11/2 inch sizes. The face-to-face dimension is 8 1/2 inches. Ensure flanges are aligned and gaskets seated to prevent leaks. Verify the system voltage matches 115V AC before wiring. Incorrect pipe sizing or debris in the line can reduce the rated flow performance.
Highlights
- Learn your heating patterns with built-in learning thermostat technology
- Delivers up to 50 gallons per minute at low head pressure
- Maintains 39 gallons per minute at moderate 5-foot head
- Provides 24 gallons per minute at 10-foot head for efficient circulation
- Flanged connections fit four pipe sizes for versatile installation
Specifications
| Brand | TACO |
|---|---|
| Type | Learning Thermostats |
Questions about this item
What flange face-to-face dimension does the 0012-SF4 require for mounting?
The pump needs an 8 1/2 in face-to-face flange spacing to bolt in place.
Which wiring step is most often missed when installing the 115V AC single-phase motor?
Connect the hot, neutral and ground leads to the junction box before energising the circuit.
When should the cartridge assembly be inspected or replaced on this 1/8 hp circulator?
Check the cartridge if flow drops below the 24 gpm at 10 ft head rating or if unusual noise appears.
