Green circuit board with single 6-pin input and twelve 6-pin outputs, toggle switch, solid capacitors, gold edge connector

SXDOOL

SXDOOL Server 6P to 12×6pin Power Board 73g

SKU CH-61D0-GPSHM

Converts a server 6P input into twelve 6-pin GPU power outputs with a self-start toggle switch and solid-capacitor filtering, tested to 1600 W and compatible with common 1200 W and 750 W server PSUs

  • Self-starts after power loss with left-switch auto mode
  • Syncs on/off with main PSU via right-switch position
  • Delivers up to 1600 W through twelve 6-pin outputs
  • Solid-capacitor filtering for stable server-power conversion
  • Weighs 73 g and fits DPS-1200FB A, DPS-1200QB A supplies

What this board does

The SXDOOL Server 6P conversion board takes a single server power supply with a gold-finger connector and distributes twelve 6-pin outputs for graphics cards. It is built for miners and compute-cluster builders who want to run multiple GPUs from one high-wattage unit.

Installation and common pitfalls

A toggle switch selects the start mode: left for automatic self-start when power returns after an outage, right for synchronised on/off with the main PSU. No output cables are included, so you must source twelve 6-pin leads separately. The board weighs 73 g and uses solid-capacitor filtering for cleaner power delivery.

Check before you buy

Verify that your server PSU uses the gold-finger pinout found on units such as the DPS-1200FB A, DPS-1200QB A, PS-2751-5Q, PS-2751-LF-1F, HSTSN-PL12, DPS-700LB D, PS-2112-5L or DPS-750RB A. The board is tested to handle up to 1600 W total draw. Ensure your motherboard has a USB 3.0 19-pin header if you plan to use the onboard 20-pin expansion for additional connectivity.

Highlights

  • Self-starts after power loss with left-switch auto mode
  • Syncs on/off with main PSU via right-switch position
  • Delivers up to 1600 W through twelve 6-pin outputs
  • Solid-capacitor filtering for stable server-power conversion
  • Weighs 73 g and fits DPS-1200FB A, DPS-1200QB A supplies

Specifications

No published specifications for this item yet.

Questions about this item

How can I verify the board is working after connecting it to a DPS-1200FB A power supply?

Set the toggle switch to the left position; the power supply should start automatically without pressing any button, confirming self-start operation.

What comes in the box and which cables must I buy separately?

The board only includes the conversion PCB with 12 six-pin headers; all output wires are sold separately.

Which version should I choose for a PS-2751-5Q unit?

This single model fits the PS-2751-5Q and other listed server supplies with the same golden-finger 6P input.
