Silver 4U rack server front with thirty-six 3.5-inch drive trays

Supermicro

Supermicro SYS-6048R-E1CR36N 36-bay 4U rack server 2x Xeon E5-2695 v4 256GB DDR4

SKU CH-3P9N-JKZGJ

A 4U rack server holding 36 hot-swap 3.5-inch drive bays with dual 18-core Xeon E5-2695 v4 processors at 2.1 GHz and 256 GB DDR4 ECC memory

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores18-Core Processor
  • Dual 18-core Xeon E5-2695 v4 processors deliver 36 threads at 2.1 GHz base clock
  • 256 GB DDR4 2400 MHz ECC memory provides large capacity for memory-intensive workloads
  • 36 hot-swap 3.5" SAS/SATA drive bays enable massive storage density in 4U form factor
  • MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60 with 1 GB cache
  • Four 10GBase-T ports via Intel X540 plus dedicated IPMI 2.0 management LAN

36-bay 4U rack server with dual Xeon E5-2695 v4

The Supermicro SYS-6048R-E1CR36N is a 4U rackmount server system built for high-density storage workloads. It ships with two Intel Xeon E5-2695 v4 18-core processors running at 2.1GHz and 256GB of DDR4 2400MHz registered ECC memory across eight 32GB modules.

Verify 3.5-inch drive trays

This unit includes 36 hot-plug 3.5-inch SATA/SAS drive trays but no hard drives are installed. Confirm your rack provides 4U of vertical space and that the LGA 2011-3 socket coolers supplied will fit your airflow layout before ordering.

Sustained load runs on dual 1280W Platinum PSUs

Under continuous operation the dual 1280-watt 80 Plus Platinum power supplies share the load for redundancy. The MegaRAID 9361-8i controller with 1GB cache and battery backup maintains RAID 0/1/5/6/10/50/60 performance during extended rebuilds or heavy I/O streams.

Highlights

  • Dual 18-core Xeon E5-2695 v4 processors deliver 36 threads at 2.1 GHz base clock
  • 256 GB DDR4 2400 MHz ECC memory provides large capacity for memory-intensive workloads
  • 36 hot-swap 3.5" SAS/SATA drive bays enable massive storage density in 4U form factor
  • MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60 with 1 GB cache
  • Four 10GBase-T ports via Intel X540 plus dedicated IPMI 2.0 management LAN

Specifications

BrandSUPERMICRO
SeriesCSE-847BE1C-R1K28LPB-X10DRi-T4+
ModelSYS-6048R-E1CR36N
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 2011-3
Number of CPU Cores18-Core Processor
# of Processors InstalledE5-2695 V4
Installed Memory Size256GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T LAN with Intel X540 Ethernet Controller
Management PortRJ 45
Features36 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

What comes with the SYS-6048R-E1CR36N and what must I add?

The server includes two Xeon E5-2695 v4 processors, 256GB DDR4 memory in eight modules, a MegaRAID 9361-8i controller, 36 drive trays, quad 10GBase-T ports, IPMI 2.0 and two 1280W power supplies. Hard drives, front bezel and rack rails are not included.

How do I choose between the listed drive-bay counts?

This model is fixed at 36 hot-swap 3.5" bays — 24 front and 12 rear — so there is no alternative bay-count version to select.

What does the 2.1GHz Xeon figure mean once the server is running?

Each of the two 18-core Xeon E5-2695 v4 CPUs runs at a 2.1GHz base clock and can turbo to 3.3GHz, delivering 36 total cores for parallel workloads.
