Silver 4U rack chassis with 36 front drive trays and dual power supplies

Supermicro

Supermicro SYS-6048R-E1CR36N 36-bay 4U rack server 2x Xeon E5-2695 v4 2.1GHz 18-core 16GB DDR4

SKU CH-BAEM-EH3GP

4U rack server with 36 hot-swap 3.5-inch drive bays, dual 18-core Xeon processors at 2.1GHz, 16GB DDR4 ECC memory, MegaRAID 9361-8i controller, quad 10GBase-T LAN and IPMI 2.0 management

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores18-Core Processor
  • Dual 18-core Xeon E5-2695 v4 processors deliver 2.1 GHz base and 3.3 GHz turbo performance
  • 36 hot-swap 3.5-inch SAS/SATA drive bays provide massive high-density storage capacity
  • LSI MegaRAID 9361-8i hardware RAID controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • Quad 10GBase-T LAN ports via Intel X540 enable high-speed 10G networking
  • IPMI 2.0 with dedicated RJ45 port offers KVM-over-LAN and virtual media remote management

Dense Storage Server

This 4U rackmount system delivers 36 hot-swap 3.5-inch bays for SAS and SATA drives, driven by dual Xeon E5-2695 v4 processors at 2.1 GHz with 18 cores each. It targets organisations that need maximum capacity in a single chassis for archiving, backup or media repositories.

Enterprise Chassis and Connectivity

Redundant 1280 W Platinum power supplies and the LSI MegaRAID 9361-8i controller with 1 GB cache and battery back-up protect data during power events. Four 10GBase-T ports on the Intel X540 controller and a dedicated IPMI 2.0 RJ45 management port provide high-throughput networking and out-of-band control without extra cards.

Platform Limits

The LGA 2011-3 platform caps memory at 24 DDR4 slots and processors at 145 W TDP, so very large memory footprints or higher-core-count CPUs require a newer generation. The 8-port RAID controller serves only eight drives directly; the remaining 28 bays need expander backplanes or additional HBAs. No front bezel or rack rails are included.

Highlights

  • Dual 18-core Xeon E5-2695 v4 processors deliver 2.1 GHz base and 3.3 GHz turbo performance
  • 36 hot-swap 3.5-inch SAS/SATA drive bays provide massive high-density storage capacity
  • LSI MegaRAID 9361-8i hardware RAID controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • Quad 10GBase-T LAN ports via Intel X540 enable high-speed 10G networking
  • IPMI 2.0 with dedicated RJ45 port offers KVM-over-LAN and virtual media remote management

Specifications

BrandSUPERMICRO
SeriesCSE-847BE1C-R1K28LPB-X10DRi-T4+
ModelSYS-6048R-E1CR36N
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 2011-3
Number of CPU Cores18-Core Processor
# of Processors InstalledE5-2695 V4
Installed Memory Size16GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T LAN with Intel X540 Ethernet Controller
Management PortRJ 45
Features36 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

What RAID levels does the 9361-8i controller support and what throughput does its SAS interface cap at?

The MegaRAID 9361-8i supports RAID 0, 1, 5, 6, 10, 50 and 60 and its SAS 12Gb/s interface caps drive throughput at 12Gb/s per port.

What physical space and mounting hardware does this 4U chassis require?

The CSE-847 chassis occupies 4U of rack height, uses 3.5" drive trays for 24 front and 12 rear bays, and ships without front bezel or rack-mount rails.

How are the dual Xeon E5-2695 v4 processors installed and what step is often missed?

Each processor seats in an LGA 2011-3 socket; the commonly missed step is applying thermal paste and torquing the heatsink retention screws in the prescribed diagonal sequence.
