Silver 2U rack server front with twelve 3.5-inch drive bays

Supermicro

Supermicro SYS-6028U-TR4T+ rack server 2x Xeon E5-2660 v4 14-core 2.0GHz 256GB DDR4 12x 3.5" bays

SKU CH-GYJ2-D8VYV

Dual 14-core Xeon 2U server with 256GB DDR4, 12 hot-swap 3.5" bays, quad 10GBase-T and redundant 1000W supplies

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.00 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores14-Core Processor
  • Dual Xeon processors deliver 28 total cores for heavy workloads
  • 256 GB DDR4 ECC memory handles large datasets reliably
  • LSI MegaRAID 9361-8i supports RAID 0/1/5/6/10/50/60 for flexible storage protection
  • Twelve hot-swap 3.5" bays provide high-capacity SAS or SATA expansion
  • Quad 10GBase-T ports via Intel X540 enable fast network throughput

Dual-socket Xeon E5-2660 v4 server

The Supermicro SYS-6028U-TR4T+ is a 2U rackmount system built around two Intel Xeon E5-2660 v4 processors. Each CPU runs at 2.0 GHz with 14 cores and a 3.2 GHz turbo frequency. It targets organisations that need dense compute for virtualization, databases or cloud workloads. The chassis fits a standard 1U rack height and uses redundant hot-swap power supplies.

MegaRAID 9361-8i controller and 10GBase-T networking

The included LSI MegaRAID 9361-8i adds hardware RAID 0, 1, 5, 6, 10, 50 and 60 across eight SAS 12Gb/s ports with 1 GB cache and a battery backup unit. A SuperMicro AOC-2UR-6-i4XT card provides four RJ45 10GBase-T ports driven by an Intel X540 controller. IPMI 2.0 with a dedicated management port enables remote KVM and virtual media over LAN.

256 GB DDR4 registered ECC memory installed

The system ships with 256 GB of DDR4 2400 MHz registered ECC memory populated across eight 32 GB modules. Twenty-four DIMM slots are available in total, supporting a maximum of 1.5 TB when fully loaded. Buyers who need more memory capacity at purchase should verify slot availability before ordering.

Highlights

  • Dual Xeon processors deliver 28 total cores for heavy workloads
  • 256 GB DDR4 ECC memory handles large datasets reliably
  • LSI MegaRAID 9361-8i supports RAID 0/1/5/6/10/50/60 for flexible storage protection
  • Twelve hot-swap 3.5" bays provide high-capacity SAS or SATA expansion
  • Quad 10GBase-T ports via Intel X540 enable fast network throughput

Specifications

BrandSUPERMICRO
SeriesCSE-829UAC-R1K02-T
ModelSYS-6028U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.00 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors InstalledE5-2660 V4
Installed Memory Size256GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSuperMicro AOC-2UR-6-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

How often will the 1000 Watt Titanium power supplies need replacement in a 24/7 environment?

Titanium-efficiency units typically run cooler than lower-rated supplies, extending internal component life; plan on a five-to-seven-year cycle under continuous load.

What thermal limit appears first when both Xeon E5-2660 v4 processors sustain 3.2 GHz turbo across all 14 cores?

The 1U chassis airflow path saturates before the CPU TDP ceiling, so inlet temperature and fan speed become the governing constraints.

How loud are the fans when the system idles versus full 10GBase-T throughput all day?

Idle noise stays near 45 dBA; sustained 10 GbE traffic pushes fans to 60 dBA as the 1000 W PSUs and X540 controller add heat.
