Black 2U rack server with twelve front 3.5-inch drive trays

Supermicro

Supermicro SYS-6028U-TR4T+ 2U rack server 2x Xeon E5-2699 v4 22-core 64GB DDR4 12x 3.5" bays

SKU CH-MK9X-R62W0

2U dual-socket server with two 22-core Xeon E5-2699 v4 CPUs, 64GB DDR4 ECC memory, MegaRAID 9361-8i controller and twelve 3.5-inch hot-swap bays

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores22-Core Processor
  • Dual Xeon E5-2699 v4 processors with 22 cores each at 2.2 GHz
  • 64GB DDR4 2400MHz registered ECC memory installed
  • LSI MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • 12 hot-swap 3.5" SATA/SAS drive bays for high-capacity storage
  • Quad 10GBase-T ports via Intel X540 plus dedicated IPMI 2.0 management

Dual-socket Xeon 2U server

The Supermicro SYS-6028U-TR4T+ is a 2U rackmount server system built around two Intel Xeon E5-2699 v4 processors. Each CPU delivers 22 cores at 2.2 GHz with a 3.6 GHz turbo frequency. The platform includes 64 GB of DDR4 2400 MHz registered ECC memory across four 16 GB modules. A MegaRAID 9361-8i controller provides eight SAS 12 Gb/s ports with 1 GB cache and battery backup.

Suits virtualisation and database hosts.

This configuration fits workloads that benefit from high core counts and large memory capacity such as virtualisation clusters, database servers and private cloud nodes. The quad-port Intel X540 10GBase-T adapter supplies 10 GbE connectivity out of the box. Buyers who need GPU acceleration or more than eight internal SAS ports should look at a different platform.

12 hot-swap 3.5-inch drive bays define storage

The chassis provides twelve front-accessible 3.5-inch trays that accept both SATA and SAS drives. No drives are installed, so total capacity depends entirely on the disks you populate. The 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50 and 60 across those bays.

Highlights

  • Dual Xeon E5-2699 v4 processors with 22 cores each at 2.2 GHz
  • 64GB DDR4 2400MHz registered ECC memory installed
  • LSI MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • 12 hot-swap 3.5" SATA/SAS drive bays for high-capacity storage
  • Quad 10GBase-T ports via Intel X540 plus dedicated IPMI 2.0 management

Specifications

BrandSUPERMICRO
SeriesCSE-829UAC-R1K02-T
ModelSYS-6028U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores22-Core Processor
# of Processors InstalledE5-2699 V4
Installed Memory Size64GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSuperMicro AOC-2UR-6-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

How do I install the 2x Xeon E5-2699 v4 processors into the LGA 2011-3 sockets, and what step is often missed?

Align the processor notches with the socket keys, lower gently, and close the retention lever; the step often missed is applying thermal paste evenly before mounting the heatsinks.

What maintenance will the MegaRAID 9361-8i controller battery need later?

The 1GB cache battery on the MegaRAID 9361-8i should be checked annually and replaced every 3 to 5 years to preserve write-back caching during power loss.

What limit appears first when the 2x 1000 Watt Titanium power supplies run under sustained full load?

The 1000W per supply rating is the first limit; sustained draw above that will trigger throttling or shutdown even with redundant units installed.
