Silver 2U rack server front with twelve 3.5 inch drive bays

Supermicro

Supermicro SYS-6028U-TR4T+ 2U rack server 2x Xeon E5-2699 v4 22-core 32GB DDR4 12x 3.5" bays

SKU CH-YH8P-QN952

2U rack server with dual 22-core Xeon E5-2699 v4 processors, 32GB DDR4 ECC memory, twelve 3.5-inch hot-swap drive bays, MegaRAID 9361-8i controller, quad 10GBase-T ports and dual 1000W power supplies

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores22-Core Processor
  • Dual Xeon E5-2699 v4 CPUs provide 22 cores each at 2.2 GHz
  • 32 GB DDR4 2400 MHz registered ECC memory installed
  • LSI MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • Twelve 3.5-inch hot-swap drive bays for SAS or SATA storage
  • Quad 10GBase-T ports via Intel X540 plus dedicated IPMI 2.0 management

Dual 22-Core Xeon 2U Server

The Supermicro SYS-6028U-TR4T+ is a 2U rackmount server system built around two Intel Xeon E5-2699 v4 processors. Each CPU runs at 2.2 GHz with a 3.6 GHz turbo frequency and provides 22 cores. The system ships with 32 GB of DDR4 2400 MHz registered ECC memory installed across four modules.

Suited for multi-threaded server workloads

This server suits buyers who need high core counts and 10 GbE networking in a 2U form factor. Twelve hot-swap 3.5-inch drive bays and an LSI MegaRAID 9361-8i controller support RAID 0, 1, 5, 6, 10, 50 and 60 for SATA or SAS storage. Builders who need more than two processors, more than 1.5 TB of memory, or GPU compute acceleration should look at other platforms.

12 hot-swap 3.5-inch bays define storage capacity

The chassis provides twelve front-accessible 3.5-inch trays for SATA or SAS hard drives, with no drives included. The MegaRAID 9361-8i controller manages the arrays and includes 1 GB cache with battery backup. Quad 10GBase-T ports on the Intel X540 controller and a dedicated IPMI 2.0 LAN port handle data and management networking. Redundant 1000 W titanium power supplies complete the configuration.

Highlights

  • Dual Xeon E5-2699 v4 CPUs provide 22 cores each at 2.2 GHz
  • 32 GB DDR4 2400 MHz registered ECC memory installed
  • LSI MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • Twelve 3.5-inch hot-swap drive bays for SAS or SATA storage
  • Quad 10GBase-T ports via Intel X540 plus dedicated IPMI 2.0 management

Specifications

BrandSUPERMICRO
SeriesCSE-829UAC-R1K02-T
ModelSYS-6028U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores22-Core Processor
# of Processors InstalledE5-2699 V4
Installed Memory Size32GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSuperMicro AOC-2UR-6-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

What memory must I already have to populate the remaining DIMM slots?

The system uses DDR4 2400 MHz registered ECC modules; four 8 GB sticks are installed leaving 20 slots open for identical DDR4 RDIMMs.

Will the LSI MegaRAID 9361-8i controller manage my existing 3.5-inch SATA or SAS drives?

Yes, the 9361-8i supports RAID 0, 1, 5, 6, 10, 50, 60 on SATA and SAS drives connected to the 12 hot-plug bays.

How can I confirm the IPMI 2.0 interface is responding after installation?

Connect the dedicated RJ45 management port, browse to its IP address, and verify the KVM-over-LAN console and virtual media functions load.
