Silver 2U rack server front with twelve 3.5 inch drive trays and bezel removed

Supermicro

Supermicro SYS-6028U-TR4T+ 2U rack server 2x Xeon E5-2697 v4 2.3GHz 18-core 256GB DDR4 12x 3.5" trays

SKU CH-9MKT-62ERA

Dual 18-core Xeon server with 256 GB DDR4, 12 hot-swap 3.5" bays, quad 10 GbE and redundant 1000 W power

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.30 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores18-Core Processor
  • Dual 18-core Xeon processors at 2.3 GHz turbo to 3.6 GHz for heavy compute
  • 256 GB DDR4 ECC registered memory across 24 slots supports up to 1.5 TB
  • 12 hot-swap 3.5" SATA/SAS bays with MegaRAID 9361-8i controller for RAID 0/1/5/6/10/50/60
  • Quad 10GBase-T ports via Intel X540 for high-throughput networking
  • IPMI 2.0 with KVM-over-LAN plus dual 1000 W titanium-efficiency power supplies for remote management and uptime

Dual Xeon E5-2697 v4 2U server

This 2U rackmount server ships with two Intel Xeon E5-2697 v4 processors running at 2.3 GHz with 18 cores each. It includes 256 GB of DDR4 registered ECC memory across eight 32 GB modules. Twelve hot-swap 3.5-inch drive bays accept SATA or SAS drives. The system targets virtualization hosts, database clusters and cloud workloads that need dual-socket density in a short rack depth.

Sustained load with redundant titanium power

Two 1000 W titanium-efficiency power supplies share the load and provide full redundancy for continuous operation. The LSI MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50 and 60 with 1 GB cache and battery backup. Quad 10GBase-T ports on the Intel X540 controller deliver consistent throughput for storage replication and VM migration. IPMI 2.0 with KVM-over-LAN allows remote monitoring and power control without physical access.

Rail mounting and drive tray handling

Front bezel and rack rails are not included, so compatible sliding rails must be sourced separately for the 2U chassis. The twelve drive trays install tool-free but require 3.5-inch drives; 2.5-inch SSDs need adapters not supplied. Memory population follows a 24-slot DDR4 layout; the installed 256 GB uses eight slots leaving room for expansion up to 1.5 TB. GPU options are limited to the onboard Matrox G200 with 8 MB video memory.

Highlights

  • Dual 18-core Xeon processors at 2.3 GHz turbo to 3.6 GHz for heavy compute
  • 256 GB DDR4 ECC registered memory across 24 slots supports up to 1.5 TB
  • 12 hot-swap 3.5" SATA/SAS bays with MegaRAID 9361-8i controller for RAID 0/1/5/6/10/50/60
  • Quad 10GBase-T ports via Intel X540 for high-throughput networking
  • IPMI 2.0 with KVM-over-LAN plus dual 1000 W titanium-efficiency power supplies for remote management and uptime

Specifications

BrandSUPERMICRO
SeriesCSE-829UAC-R1K02-T
ModelSYS-6028U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.30 GHz
CPU SocketLGA 2011-3
Number of CPU Cores18-Core Processor
# of Processors InstalledE5-2697 V4
Installed Memory Size256GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSuperMicro AOC-2UR-6-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

How much power will the twin 1000 W Titanium supplies draw under full load?

Each supply is rated at 1000 W with Titanium efficiency, so typical full-load draw stays well within that envelope while keeping heat and fan speed moderate.

Which cables or rails are required to mount the chassis and connect the 12 drive bays?

The unit ships with 12 hot-swap 3.5" trays and redundant power supplies; you must supply rack rails, a front bezel and SAS/SATA cables for the backplane.

Will the LSI 9361-8i controller recognise older 6 Gb/s SAS drives in the backplane?

Yes — the MegaRAID 9361-8i supports 12 Gb/s SAS and is backward-compatible with 6 Gb/s and 3 Gb/s SAS or SATA drives across all 12 bays.
