Silver 2U rack server front panel with twelve 3.5 inch drive bays

Supermicro

Supermicro SYS-6028U-TR4T+ 2U rack server 2x Xeon E5-2697 v4 2.3GHz 18-core 32GB DDR4 12x 3.5" bays

SKU CH-KJ8Y-08D48

2U rack server with dual 18-core Xeon processors at 2.3 GHz, 32 GB DDR4, 12 hot-swap 3.5-inch drive bays, quad 10 GbE ports and dual 1000 W power supplies

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.30 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores18-Core Processor
  • Dual 18-core Xeon processors at 2.3 GHz deliver 36 threads for heavy compute
  • 32 GB DDR4 ECC memory installed across 24 DIMM slots for reliability
  • 12 hot-swap 3.5" drive bays support SAS and SATA storage expansion
  • Quad 10GBase-T Ethernet ports via Intel X540 controller for high-speed networking
  • Redundant 1000 W Titanium power supplies and IPMI 2.0 remote management ensure uptime

Dual Xeon 2U server for virtualization workloads

The Supermicro SYS-6028U-TR4T+ is a 2U rackmount system built around two Intel Xeon E5-2697 v4 processors running at 2.3 GHz with 18 cores each. It ships with 32 GB of DDR4 registered ECC memory across four modules. Twelve hot-plug 3.5-inch drive bays accept SATA or SAS disks for high-capacity storage arrays.

MegaRAID 9361-8i controller with eight SAS ports

The installed LSI MegaRAID 9361-8i provides eight internal 12 Gb/s SAS ports and 1 GB of battery-backed cache. It supports RAID 0, 1, 5, 6, 10, 50 and 60 so you can tune redundancy and performance to the workload. Only eight drives connect directly to the controller; the remaining four bays require an additional HBA or expander.

Quad 10GBase-T networking and IPMI 2.0 management

A SuperMicro AOC-2UR-6-i4XT add-in card adds four RJ45 10GBase-T ports driven by an Intel X540 controller for high-throughput LAN connectivity. A dedicated RJ45 IPMI 2.0 port enables KVM-over-LAN and virtual media for full out-of-band management. Redundant 1000 W titanium power supplies are included, but front bezel and rack rails are not.

Highlights

  • Dual 18-core Xeon processors at 2.3 GHz deliver 36 threads for heavy compute
  • 32 GB DDR4 ECC memory installed across 24 DIMM slots for reliability
  • 12 hot-swap 3.5" drive bays support SAS and SATA storage expansion
  • Quad 10GBase-T Ethernet ports via Intel X540 controller for high-speed networking
  • Redundant 1000 W Titanium power supplies and IPMI 2.0 remote management ensure uptime

Specifications

BrandSUPERMICRO
SeriesCSE-829UAC-R1K02-T
ModelSYS-6028U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.30 GHz
CPU SocketLGA 2011-3
Number of CPU Cores18-Core Processor
# of Processors InstalledE5-2697 V4
Installed Memory Size32GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSuperMicro AOC-2UR-6-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

What does having 2 Xeon E5-2697 v4 18-core processors at 2.3GHz mean for actual workloads?

The dual 18-core CPUs provide 36 physical cores at 2.3GHz base with 3.6GHz turbo, suited for virtualization hosts, database servers and compute clusters that scale across many threads.

What does the LSI MegaRAID 9361-8i 12Gb/s controller cap in practice?

The 8-port 12Gb/s SAS controller handles RAID 0/1/5/6/10/50/60 with 1GB cache and battery backup, limiting direct connections to eight drives while the backplane serves twelve bays.

What does the 2U chassis need to mount in a standard rack?

The unit fits a 2U rack space with redundant 1000W hot-swap power supplies; front bezel and rack rails are not included and must be sourced separately.
