Supermicro
Supermicro SYS-6028U-TR4T+ 2U rack server 2x Xeon E5-2695 v4 2.1GHz 18-core 256GB DDR4 12x 3.5" bays
Dual Xeon 18-core 2U server with 256GB DDR4, 12 hot-swap 3.5" bays, quad 10GBase-T and IPMI 2.0
- Rack Height1U
- Redundant Hot-swap PowerYes
- CPU TypeIntel Xeon
- CPU Speed2.10 GHz
- CPU SocketLGA 2011-3
- Number of CPU Cores18-Core Processor
- Dual Xeon E5-2695 v4 CPUs deliver 36 cores at 2.1GHz
- 256GB DDR4 2400MHz ECC memory supports heavy workloads
- MegaRAID 9361-8i enables RAID 0/1/5/6/10/50/60
- 12 hot-swap 3.5" bays fit SAS or SATA drives
- Quad 10GBase-T ports via Intel X540 for fast networking
Dual-Socket 2U Server Platform
The Supermicro SYS-6028U-TR4T+ is a 2U rackmount server equipped with two Intel Xeon E5-2695 v4 processors running at 2.1 GHz with 18 cores each. It ships with 256 GB of DDR4 2400 MHz registered ECC memory installed across eight 32 GB modules. The system includes a MegaRAID 9361-8i controller with 1 GB cache and battery backup, plus an Intel X540 quad-port 10GBase-T network adapter.
Suited for Virtualisation and Database Workloads
This configuration targets environments that need high core counts and large memory capacity for virtualization, database management, or cloud computing tasks. The twelve 3.5-inch hot-plug SATA/SAS drive bays support RAID levels 0, 1, 5, 6, 10, 50, and 60 for flexible storage layouts. Buyers who need GPU acceleration or front bezel and rack rails included should evaluate other options.
Twelve 3.5-Inch Hot-Plug Drive Bays
The chassis provides twelve front-accessible 3.5-inch trays for SATA or SAS drives, enabling dense storage in a 2U form factor. No drives are installed, so the buyer must supply media matching the workload. Redundant 1000 W titanium-efficiency power supplies and IPMI 2.0 with dedicated LAN complete the platform.
Highlights
- Dual Xeon E5-2695 v4 CPUs deliver 36 cores at 2.1GHz
- 256GB DDR4 2400MHz ECC memory supports heavy workloads
- MegaRAID 9361-8i enables RAID 0/1/5/6/10/50/60
- 12 hot-swap 3.5" bays fit SAS or SATA drives
- Quad 10GBase-T ports via Intel X540 for fast networking
Specifications
| Brand | SUPERMICRO |
|---|---|
| Series | CSE-829UAC-R1K02-T |
| Model | SYS-6028U-TR4T+ |
| Rack Height | 1U |
| Redundant Hot-swap Power | Yes |
| CPU Type | Intel Xeon |
| CPU Speed | 2.10 GHz |
| CPU Socket | LGA 2011-3 |
| Number of CPU Cores | 18-Core Processor |
| # of Processors Installed | E5-2695 V4 |
| Installed Memory Size | 256GB |
| Storage Controller | LSI MegaRAID 9361-8i Controller |
| HDD Interface | SATA/SAS |
| SSD (Installed) | No |
| Raid Level | RAID 0/1/5/6/10/50/60 |
| GPU Type | Matrox G200 |
| Video Memory | 8MB |
| Ethernet Controller | SuperMicro AOC-2UR-6-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports |
| Management Port | RJ 45 |
| Features | 12 x 3.5" SATA/SAS Hot-Plug Drive Bays |
Questions about this item
Will the 18-core Xeon E5-2695 v4 CPUs hit thermal limits during continuous heavy workloads?
The 2U chassis uses redundant 1000 W Titanium supplies and hot-swap fans designed for sustained dual-socket operation at 2.1 GHz base and 3.3 GHz turbo.
How loud and hot does the server get when running 24/7 with both 18-core processors loaded?
Dual 1000 W power supplies and multiple system fans keep temperatures within spec; acoustic output is typical for a 2U rackmount with redundant cooling.
Which components are missing from the 12-bay 3.5" chassis that I must supply before the server will boot?
No hard drives, front bezel or rack rails are included; you must add SAS or SATA drives, and optionally rails and bezel, to complete the system.
