Silver 2U rack server with twelve front 3.5-inch drive trays and dual power supplies

Supermicro

Supermicro SYS-6028U-TR4T+ 2U rack server 2x Xeon E5-2690 v4 14-core 2.6GHz 768GB DDR4 12-bay 3.5

SKU CH-NXEF-KDYKY

Dual Xeon E5-2690 v4 14-core 2.6 GHz server with 768 GB DDR4, 12 hot-swap 3.5″ bays, MegaRAID 9361-8i, quad 10GBase-T and IPMI 2.0 in 2U

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.60 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores14-Core Processor
  • Dual 14-core Xeon processors at 2.6 GHz for heavy multi-threaded workloads
  • 768 GB DDR4 ECC memory across 24 slots for large in-memory datasets
  • MegaRAID 9361-8i controller with 1 GB cache enables RAID 0/1/5/6/10/50/60
  • Twelve hot-swap 3.5-inch SATA/SAS bays for high-capacity storage growth
  • Quad 10GBase-T ports via Intel X540 plus IPMI 2.0 for fast remote management

Dual-socket Xeon server for dense compute

The Supermicro SYS-6028U-TR4T+ is a 2U rackmount system fitted with two 14-core Xeon E5-2690 v4 processors at 2.6 GHz and 768 GB of DDR4 ECC memory. Twelve hot-swap 3.5-inch bays accept SATA or SAS drives managed by a MegaRAID 9361-8i controller with battery-backed cache. Quad 10GBase-T ports and IPMI 2.0 with KVM-over-LAN complete the enterprise feature set. Redundant 1000 W titanium-efficiency supplies power the chassis.

Suits virtualization hosts.

Teams that need high core counts, large memory capacity and 10 GbE networking in a compact 2U form factor will find the specifications well matched. Buyers who require more than twelve drive bays, GPU acceleration or a different processor generation should evaluate other platforms. The fixed 768 GB memory population also limits configurations that demand either less or more RAM out of the box.

Twelve 3.5-inch hot-swap bays with MegaRAID 9361-8i

Storage density is defined by the twelve front-accessible trays and the eight-port SAS 12 Gb/s RAID card supporting RAID 0, 1, 5, 6, 10, 50 and 60. This combination determines how many spindles the server can address and which redundancy schemes are available without adding an external enclosure.

Highlights

  • Dual 14-core Xeon processors at 2.6 GHz for heavy multi-threaded workloads
  • 768 GB DDR4 ECC memory across 24 slots for large in-memory datasets
  • MegaRAID 9361-8i controller with 1 GB cache enables RAID 0/1/5/6/10/50/60
  • Twelve hot-swap 3.5-inch SATA/SAS bays for high-capacity storage growth
  • Quad 10GBase-T ports via Intel X540 plus IPMI 2.0 for fast remote management

Specifications

BrandSUPERMICRO
SeriesCSE-829UAC-R1K02-T
ModelSYS-6028U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.60 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors InstalledE5-2690 V4
Installed Memory Size768GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSuperMicro AOC-2UR-6-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

Will my existing LGA 2011-3 Xeon processors work alongside the installed 2.6GHz 14-core E5-2690 v4 CPUs?

The server uses dual LGA 2011-3 sockets populated with two E5-2690 v4 14-core processors at 2.6GHz; matching CPUs must share the same socket and QPI speed for proper operation.

How can I verify the MegaRAID 9361-8i controller and quad 10GBase-T ports are functioning after installation?

Check the controller BIOS during POST for the 9361-8i with 1GB cache, confirm all four Intel X540 10GBase-T RJ45 links show active, and use IPMI 2.0 KVM-over-LAN to monitor system health remotely.

Which drive trays and mounting hardware are included, and what must I source separately?

Twelve 3.5-inch SAS/SATA hot-plug trays are supplied; hard drives, front bezel and rack-mount rails are not included and must be purchased separately.
